Compass D3 plus Montageanleitung Seite 25

Teile-Nr. Beschreibung
02-0302 Cooling Fan Hub
02-0304 Cooling Fan
02-0307 Starter Coupling
02-0309 Crank Case Holder
02-0312 Clutch Liner
02-0318G Starter Bearing Block
02-0321 Clutch Bell
02-0325 Clutch
02-0326 Start Shaft
02-0332 Engine Mount Base
02-0334OS Crank Case Dampener OS
02-0334YS Crank Case Dampener YS
02-0335 Engine Dampener
02-0337 Engine Mount Washer
02-0503G Washout Base (grey)
02-0518 Washout Link
02-0519G Phasing Control Ring
02-0532 Bushing
02-0535 Washout Control Arm
02-0601 Main Shaft
02-8305 Engine Mount Set
05-0606 Main Shaft Lock Clamp (Ø
06-0410S Swashplate Pin
07-0621 Autorotation Hub
07-0622 Autorotation Sleeve
07-0623 Main Pulley Hub
07-4302 Drive gear
07-4501 Main Pulley
07-4603 Main Gear Molded
07-8410 Swashplate
60-10195 Ball Bearing 10x19x5
60-12215 Ball Bearing 12x21x5
60-4083 Ball Bearing 4x8x3
60-6124 Ball Bearing 6x12x4
60-6196 Ball Bearing 6x19x6
61-2562 Flanged Bearing 2.5x6x2.6
62-101412 One Way Bearing 10x14x12
62-121816 One Way Bearing 12x18x16
79-0306 Button Head Bolt M3x6
Button Head Bolt M3x8
79-0308
80-0206S Cap Head Bolt M2x6
80-0306 Cap Head Bolt M3x6
80-0308 Cap Head Bolt M3x8
80-0310 Cap Head Bolt M3x10
80-0312 Cap Head Bolt M3x12
80-0327 Shanked Bolt M3x27
80-2505 Button Head Bolt M2.5X5
80-2510 Cap Head Bolt M2.5×10
Cap Head Bolt M2.5x15
80-2514
81-0406 Set Screw M4x6
91-0003 Nylon Lock Nut M3
Bestell-Nr. Bestell-Beschreibung
Cooling Fan Hub
02-0302
02-0304 Cooling Fan
02-0307S Starter Coupling
02-0309 Crank Case Holder
02-0312 Clutch Liner
Starter Bearing Block
02-0318G
02-0321Z Clutch Bell set
02-0325Z Clutch set
02-0326 Start Shaft set
Engine Mount Base
02-0332
Crank Case Dampener OS
02-0334OS
02-0334YS Crank Case Dampener YS
02-0335 Engine Dampener set
02-0337 Engine Mount Washer set
Washout Base (grey)
02-0503G
02-0518 Washout Links
02-0519G Phasing Control Ring (grey)
02-0531S Bushing set (3 sizes)
Washout Control Arm set
02-0535
Main Shaft
02-0601
02-8305 Engine Mount Set
05-0606S Main Shaft Lock Clamp set (Ø 10mm)
06-0410S Swashplate Pin Set
Autorotation Hub w, One Way Bearing
07-0621Z
Autorotation Sleeve
07-0622
07-0623 Main Pulley Hub
07-4302 Drive gear
07-4501 Main Pulley
Main Gear Molded
07-4603
07-8410 Swashplate
60-10195 Ball Bearing 10x19x5
60-12215 Ball Bearings 12x21x5
Ball Bearings 4x8x3
60-4083
Ball Bearings 6x12x4
60-6124
60-6196 Ball Bearings 6x19x6
61-2562 Flanged Bearings 2.5x6x2.6
62-101412 One Way Bearing 10x14x12
One Way Bearing 12x18x16
62-121816
Button Head Bolts M3x6
79-0306
Button Head Bolts M3x8
79-0308
80-0206S Cap Head Bolts M2x6
80-0306 Cap Head Bolts M3x6
Cap Head Bolts M3x8
80-0308
80-0310 Cap Head Bolts M3x10
80-0312 Cap Head Bolts M3x12
80-0327 Shanked Bolts M3x27
Button Head Bolts M2.5X5
80-2505
Cap Head Bolts M2.5×10
80-2510
Cap Head Bolts M2.5x15
80-2514
81-0406 Set Screws M4x6
91-0003 Nylon Lock Nuts M3
Menge
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 set/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
2 pcs/bag
2 pcs/bag
1pcs/bag
2 pcs/bag
1 pcs/bag
6 pcs/bag
2 pcs/bag
1 pcs/bag
1 set/bag
1pcs/bag
1 set/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 set/bag
4 pcs/bag
2 pcs/bag
5 pcs/bag
2 pcs/bag
2 pcs/bag
10 pcs/bag
1 set/bag
1 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
