Compass D3 plus Montageanleitung Seite 27

Teile-Nr. Beschreibung
02-0306 Cooling fan shroud (3D Plus)
02-0604 Bearing block lower
02-0605G Bearing block upper
02-0606 Fan Shroud Mount
02-0804 Frame Spacer 13.5mm
02-0805 Cross Member M3x30
02-0815 Battery Tray (3Dplus)
02-0820 Skid End Cap
02-0821 Landing Gear Skid
02-0822 Landing Gear Strut (3D Plus)
02-0827 Tank Mount
02-0831 Main Frame
02-0841 Canopy Standoff
02-0845 Frame Member
02-0846 Tank Dampener
02-0847 Frame Member
02-0848 Frame Member
02-0849 Frame Member
02-1802 Bottom Frame Stiffener
02-1805 Cross Member Mount M3x30
02-1825 Tail Boom Mount
02-1833 Back Frame Stiffener
02-1843 Gyro Tray plastic
02-4811 Tank Cap
Nozzle
02-8811 Fuel Tank Assembly
Guide Pulley
05-0805
07-0806 Guide Pulley Mount
07-0820 Tank Cap Connector
07-0835 Frame Member
07-0907 Swashplate Guide
07-8302 Guide Pulley set
07-8811 Tank Fitting (3D Plus)
60-10195 Ball Bearings 10x19x5
60-3095 Ball Bearing 3x9x5
Flat Head Bolt M3x8
78-0308
79-0306 Button Head Bolt M3x6
79-0308 Button Head Bolt M3x8
80-0306 Cap Head Bolt M3x6
80-0308 Cap Head Bolt M3x6
80-0310 Cap Head Bolt M3x10
80-0312 Cap Head Bolt M3x12
80-0314 Cap Head Bolt M3x14
80-0325 Cap Head Bolt M3x25
80-0338 Cap Head Bolt M3x38
81-0305 Set Screw M3x5
81-0316 Set Screw M3x16
91-0003 Nylon Lock Nut M3
95-0310 Self Tapping Bolt 3x10
95-2508 Self Tapping Bolt 2.5x8
Bestell-Nr. Bestell-Beschreibung
02-0306 Cooling fan shroud (3D Plus)
Bearing block lower set
02-0604Z
02-0605G Bearing block upper set
02-0606 Fan Shroud Mount set
02-0804 Frame Spacer set 13.5mm
Cross Member set M3x30
02-0805
Battery Tray (3Dplus)
02-0815
02-0820 Skid End Cap set
02-0821 Landing Gear Skids w. Caps
02-0822 Landing Gear Struts (3D Plus)
Tank Mount set
02-0827
02-0831 Main Frame set
02-0841S Canopy Standoff set
02-0845S Frame Member set
02-0846 Tank Dampener set
Frame Member set
02-0845S
02-0845S Frame Member set
02-0845S Frame Member set
02-1802 Bottom Frame Stiffener
Cross Member Mount set M3x30
02-1805
Tail Boom Mount set
02-1825s
02-1833 Back Frame Stiffener
02-1843 Gyro Tray plastic
02-4811 Tank Cap
Nozzle
02-5811
02-8811 Fuel Tank Assembly
Guide Pulley set
05-0805Z
07-0806 Guide Pulley Mount
07-0820 Tank Cap Connector
Frame Member
07-0835
07-0907 Swashplate Guide
07-8302 Guide Pulley Set
07-8811 Tank Fitting set (3D Plus)
Ball Bearings 10x19x5
60-10195
Ball Bearings 3x9x5
60-3095
Flat Head Bolts M3x8
78-0308
79-0306 Button Head Bolts M3x6
79-0308 Button Head Bolts M3x8
Cap Head Bolts M3x6
80-0306
80-0308 Cap Head Bolts M3x8
80-0310 Cap Head Bolts M3x10
80-0312 Cap Head Bolts M3x12
Cap Head Bolts M3x14
80-0314
Cap Head Bolts M3x25
80-0325
80-0338 Cap Head Bolts M3x38
81-0305 Set Screws M3x5
81-0316 Set Screws M3x16
Nylon Lock Nuts M3
91-0003
Self Tapping Bolts 3x10
95-0310
95-2508 Self Tapping Bolts 2.5x8
Menge
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
4 pcs/bag
5 pcs/bag
1 pcs/bag
4 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
4 pcs/bag
4 pcs/bag
8 pcs/bag
4 pcs/bag
4 pcs/bag
4 pcs/bag
1 pcs/bag
2 pcs/bag
1 set/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 set/bag
2 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 set/bag
1 set/bag
4 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
