Operating instructions
MOC3SA
8013173/YA35/2014-07-24
Subject to change without notice
Product description
No. Status
1 f < f
Limit
I2 = 2 Hz
2 f > f
Limit
I2 = 2 Hz
3 f > f
Limit
I2 = 2 Hz
4 f > f
Limit
I2 = static
5 f > f – 15 %
Limit
I2 = static
6 f < f – 15 %
Limit
I2 = static
7 f < f
Limit
I2 = static
8 f < f
Limit
I2 = 2 Hz
9 f < f
Limit
I2 = 2 Hz
10 f < f
Limit
I2 = static
11 f < f
Limit
I2 = static
12 f > f
Limit
I2 = static
13 f > f – 15 %
Limit
I2 = static
14 f < f – 15 %
Limit
I2 = static
15 f < f
Limit
I2 = 2 Hz
16 f > f
Limit
I2 = 2 Hz
17 f > f – 15 %
Limit
I2 = static
18 f < f – 15 %
Limit
I2 = static
19 f < f
Limit
I2 = 2 Hz
20 f < f
Limit
I2 = static
21 f > f
Limit
I2 = static
© SICK AG • Industrial Safety Systems • Germany • All rights reserved
Description
Valid input condition
Outputs Q1/Q2 = HIGH
Invalid input condition
State transition t < 1 s, ERR on X1 = off
Invalid input condition
ERR on X1 = process error
Valid input condition
Refresh time after error rectification
Valid input condition
Outputs Q1/Q2 = LOW
Invalid input condition
State transition t < 1 s, ERR on X1 = off
Invalid input condition
ERR on X1 = process error
Valid input condition
Outputs Q1/Q2 = HIGH
Refresh time after error rectification
Valid input condition
Outputs Q1/Q2 = HIGH
Invalid input condition
State transition t < 1 s, ERR on X1 = off
Invalid input condition
ERR on X1 = process error
Valid input condition
Refresh time after error rectification
Valid input condition
Outputs Q1/Q2 = LOW
Invalid input condition
State transition t < 1 s, ERR on X1 = off
Valid input condition
Outputs Q1/Q2 = HIGH
Invalid input condition
State transition t < 1 s, ERR on X1 = off
Valid input condition
Outputs Q1/Q2 = LOW
Invalid input condition
State transition t < 1 s, ERR on X1 = off
Valid input condition
Outputs Q1/Q2 = HIGH
Invalid input condition
State transition t < 1 s, ERR on X1 = off
Valid input condition
Outputs Q1/Q2 = LOW
en
Chapter 3
91
