2. Specifications

AC Power Source
Max. Output power 1000 W
Max. Output current 4,5 A AC
Output voltage 0-250 V AC
Fuse Input: 230 V / 50 Hz : 8 A / 250 V
115 V / 60 Hz : 15 A / 250 V
Output: 5 A auto cut-off
DC Power Supply
Output voltage 0 - 30 V DC; 5 V/3 A fixed
Output current 0 - 5 A DC
Residual ripple (U/I) < 35 mVrms / 3 mArms
DC output
Line Regulation CV 1×10-4+3mV CC2×10-3+3mA
Load Regulation CV 1×10-4+5mV CC2×10-3+5mA
Fixed output 10mV
Ripple & Noise CV 1mVrms / CC 3mArms
Fixed output 10 mV
Fixed Output Accuracy 2,5%
Accuracy of fixed output 2,5 %
Accuracy of Display +/- 1,0 % + 2 dgt.
Operation voltage 110 ~127 V / 220 ~ 240 V AC ;
50/60 Hz – switchable
Dimensions (WxHxD) 19" 3 HE-System housing, 482 x 140 x 430 mm
(housing: 430 x 140 x 390 mm)
Weight 24 kg
Additional advice to isolating transformer
®
The PeakTech 2235 is developed and manufactured in protection class I
(hereinafter known as PC I).
Equipment belonging to the PC I must carry on the input side a protection
earth conductor (PE). Even equipment that have a PE only for radio
interference elimination, such as some switching power devices, it is
automatically classified as PC I.
Special cases are PC-I devices that have the output of a type of protection
class II.
Here, the PE is omitted, but then it is necessary to output to a reinforced
insulation which exceeds the basic insulation to be respected.
