Quick Guide
Teichweg 4 + 6
Tel. +49 (0) 5 41 - 7 70 95 - 0
www.focon-showtechnic.com
49504 Lotte / Wersen
Fax. +49 (0) 5 41 - 7 70 95 - 27
info@focon-showtechnic.com
Operating Modes
Changing operating mode
Press the Enter key. The number of the current operating mode is displayed. You can
now select a different operating mode using the arrow keys.
Press the Enter key a second time. Now you can set the DMX Start Address. Press the
Enter key a third time to exit and the operating mode selected will be activated.
Mode description: ELP30 / ELP60
Mode 1
DMX: 30/60 - channel,every LED is controlled individually
Mode 2
DMX: 15/30-channel,groups of 2 neighbouring LEDs form 1 DMX channel
Mode 3
DMX: 15 - channel, groups of 4 neighbouring LEDs form 1 DMX channel
Mode 4
DMX: 6/12-channel,groups of 5 neighbouring LEDs form 1 DMX channel
Mode 5
DMX: 3/6-channel, groups of 6 neighbouring LEDs form 1 DMX channel
Mode 6
DMX: 3 - channel, all LEDs of the same colour form 1 DMX channel
Mode 7
DMX: 15/30 - channel, every 10th LED on 1 DMX channel
Mode 8
DMX: 15 - channel, every 5th LED on 1 DMX channel
Mode 9
DMX: 6/12 - channel, every 4th LED on 1 DMX channel
Mode 10
DMX: 6/12 - channel, every 2nd LED on 1 DMX channel
Mode 11
Reserved
Mode 12
Program:
Slow colour fade
Mode 13
Program:
Fast colour change
Mode 14
Program:
Fast rainbow change
Mode 15
Program:
Fast brightness change: white
Mode 16
Program:
All red
Mode 17
Program:
All green
Mode 18
Program:
All blue
Mode 19
Program:
Slow white strobe
Mode 20
Program:
Slow red/green/blue strobe
Mode 21
Program:
Fast white strobe
Mode 22
Program:
Slow red strobe
Mode 23
Program:
Slow green strobe
Mode 24
Program:
Slow blue strobe
Mode 25
Program:
Reserved
Mode 26
Program:
Red chase
Mode 27
Program:
Green chase
Mode 28
Program:
Blue chase
Mode 29
Program:
Reserved
Attention: LED assignment may vary (ELP30)
An illuminated decimal point indicates the operating state of the ELP 30 Powerstick/
ELP 60 LED Powerstick LED. Two decimal points blinking alternately in DMX mode
indicate the presence of a valid DMX signal.
Technical Specifications: ELP30 / ELP60
Physical:
Electrical:
Length:
500mm / 1000mm
Input range:
Width:
85mm
Frequency range:
Height:
83mm
Weight:
ca. 2,5kg / ca. 4,5kg
Starting current
at 25°C (<2ms ):
Chassis:
Anodized aluminium
Cover:
Acrylic glass
Current consumption:
Temperature range:
Operating:
Stored:
Photometric:
Colour:
Numbre:
Light output:
Red
10 items/ 20 items
440 / 880lm
Green
10 items/ 20 items
300 / 600lm
Blue
10 items/ 20 items
100 / 200lm
Total
30 items/ 60 items
840 / 1680lm
Automatic LED output reduction:
chassis temperature 50°: 20%
chassis temperature 60°: 50%
Optics:
choice of 12°,30°,50° or 50° x 12°
Colours:
16.7 million ( 24 - bit ) additive RGB colour mixing
Control:
USITT DMX512 / 1990 (4µs)
Connections:
DMX In 5pin XLR integrated plug
DMX Out 5pin XLR integrated socket
Attention:
Only use M10 bolt with a max. thread lenght of 30mm for backside mount.
85 -264VAC
47 - 63Hz
120VAC – 15A / 30A
230VAC – 30 / 60A
75VA / 150VA
-10°C up to +35°C
-20°C up to +75°C
Dominant wavelength:
627nm
530nm
470nm
