Introduction
Thank you for choosing this angle grinder from PRO-
BUILDER. PRO-BUILDER is a range of heavy-duty tools for
tradesmen and quality-conscious DIY enthusiasts. You have
purchased a high-quality and well-designed tool that offers
precision, durability and reliability. By following the instruc-
tions in this User Guide, your grinder will provide many years
of trouble-free use.
Please read this User Guide and the general safety instruc-
tions enclosed before using the grinder, to ensure you get
maximum use from the tool. Keep the User Guide in a safe
place as you may need to refer to it at a later date.
Use
This angle grinder can be used for grinding and smoothing
burrs, sharp edges and irregularities on items that have been
welded or cut with a cutting torch. It can also be used for
finishing various items in iron, steel, bronze, aluminuium,
epoxy-resin, slate, brick, tile, marble etc. Not suitable for
use on wood.
Technical specifications
Voltage/frequency:
Power rating:
Disc diameter (with no disc):
Speed:
Major components
1. Grinding disc
2. Spindle lock
3. On/off button
4. Ventilation slots
5. Side handle
6. Disc shield
Special safety regulations
Check that the ventilation slots are not blocked.
Always secure the item to be worked with cramps or the
like. Never hold the item to be worked by hand.
Always use the correct type of grinding/cutting disc for the
type of work to be performed.
Never use discs with a maximum RPM less than that of the
tool.
Never use oversized discs. Do not use discs with a thick-
ness greater than 8 mm.
Never use damaged or worn discs, or discs that cannot be
easily fitted to the grinder spindle. Never use an adapter
ring or the like to fit discs with holes that are too large for the
grinder spindle.
Never allow the disc to be in contact with the item to be
worked - or other objects - when starting the grinder.
Never place your hand or fingers near the disc while the
grinder is running.
Keep the power cable well clear of the working area.
Keep the handles and the grinder as a whole free of oil,
grease, water and other liquids.
Never depress the spindle lock while the disc is rotating!
Never put the grinder down until the disc has completely
stopped rotating.
Do not touch the item to be worked or metal filings until they
have cooled.
230 V ~ 50 Hz
Preparation for use
750 W
115 mm
Loosen the screw on the disc shield (6), and adjust the shield
11,000 RPM
to the required angle. The shield must be positioned to pro-
tect the user if the disc (1) shatters during use. Retighten
the screw.
Check that the spindle lock (2) is not locked and that the
disc can freely rotate.
Switch the grinder on using the on/off button (3), and let it
run for 30 seconds to check that it is working correctly and
that there are no abormal vibrations. Stop the grinder imme-
diately if heavy vibration occurs, and investigate the cause.
Use
Hold the handle and side handle firmly and switch on. Avoid
blocking the ventilation slots (4) with your hand, as this may
cause the grinder to overheat. Let the disc reach full speed.
Apply the grinder to the item. Maximum effect is achieved
when the grinder is held at an angle of 15-30° in relation to
the item.
Move the grinder gently along the item. Give the grinder
time to work. It is rarely necessary to press the disc hard
against the surface to be worked.
Sparks can occur in the motor compartment during use. This
is normal and does not mean the grinder is defective.
Switch off the grinder after use.
