INSTALLATION
Drilling the Support surface and Fitting the Hood
• The hood support surface must be 135 mm above the bottom surface of
the wall units.
• Drill the support with a ø 4,5 mm drill bit, using the drilling template pro-
vided.
• Cut a hole ø 125 mm in size on the support surface, using the drilling
template provided.
• Fix using the 4 screws 12a (4,2 x 44,4) provided.
• The space between the edge of the hood and the rear wall can be closed
by applying the element 20 provided, using the screws supplied for this
purpose.
EN
SCREW FITTING
CLOSING ELEMENT
12a
125 125
20
7 7
