Operating instructions
LED outdoor spotlight with motion detector
"Cadiz", 7,5 W
Item no. 1433330
Intended use
The product is intended to provide outdoor lighting. The built-in PIR sensor responds to tem-
perature changes within the detection range (e.g. if a person enters the detection range) and
activates the LED outdoor spotlight for an adjustable period of time.
For safety and approval reasons, you may not convert and/or alter the product. If you use the
product for purposes other than those described above, the product may be damaged. Fur-
thermore, an improper use involves risks such as short-circuit, fire, electric shocks, etc. Please
read the operating instructions carefully and do not discard them. If you pass the product on to
a third party, please hand over these operating instructions as well.
This product complies with the applicable National and European legal requirements. All names
of companies and products are the trademarks of the respective owners. All rights reserved.
Package Contents
• LED outdoor spotlight
• 2x screws
• 2x dowels
• Operating instructions
Up-to-date operating instructions
Download the latest operating instructions via the link www.conrad.com/downloads or scan the
QR code. Follow the instructions on the website.
Explanation of Symbols
The lightning symbol inside a triangle is used when there is a potential risk of per-
sonal injury, such as electric shock.
An exclamation mark in a triangle indicates important instructions in this operating
manual which absolutely have to be observed.
The arrow symbol is used to indicate where specific tips and information on handling
should be given.
The product is not dimmable.
The product is designed according to protection Class II (reinforced or double insu-
lation; protective insulation).
Observe the operating instructions!
Safety Instructions
Please read the operating instructions carefully and pay particular attention to
the safety instructions. We do not assume liability for injuries/material damag-
es resulting from failure to observe the safety instructions and the information
in these operating instructions regarding the proper handling of the product.
Furthermore, in such cases, the warranty/guarantee will be null and void.
Attention, important note!
This device should be installed only by people with relevant electro-technical
knowledge and experience! *)
If it is not installed properly, you risk:
• your own life
• the life of the user of the electrical system.
If it is not installed properly, you risk severe damage to property, e.g. by fire.
You face the risk of personal liability for personal injury and material damage.
Contact an electrician!
*) Specialist knowledge required for the installation:
For the installation, in particular, the following specialist knowledge is required:
• the „5 safety rules" to be followed: Switch off power; secure against switching back
on; determine voltage-free status; earthing and short-circuiting; cover or fence off
nearby live parts
• Choose appropriate tools, meters and, if necessary, personal protective equip-
ment
• Evaluation of the measurement results
• Selection of the electrical installation material to ensure the shutdown conditions
• IP protection types
• Installation of the electrical installation material
• Type of mains supply network (TN system, IT system, TT system) and the con-
nection conditions that follow from them (classical earthing, protective earthing,
required additional measures, etc.)
If you do not have the expertise required for the installation, do not connect
and install it yourself but ask a qualified technician.
• The product is not a toy and should be kept out of the reach of children! There is
danger of a life-threatening electric shock!
• The product may only run on mains voltage (see section "Technical Data"). Never
try to operate the product at another voltage, as this will result in the destruction
of the product.
• During installation, all poles must be disconnected from the mains voltage via a
cut-off device (e.g., an RCD).
• The product is suitable for installation and use in outdoor areas. However, it must
not be installed in or under water, there is a danger of a fatal electric shock!
Furthermore, pay attention to the correct mounting position; the PIR sensor must
point downwards (see chapter "Preparation for Installation and Connection").
• Only use the product when it is firmly mounted/steady.
• Never install or use the product in or on vehicles.
• Do not use the product in rooms with adverse environmental conditions, where
combustible gases, vapours or dust are or may be present! There is a danger of
explosion!
• The product must not be exposed to extreme temperatures, direct sunlight, strong
vibrations, dust, dirt or heavy mechanical stress. Keep the product away from
strong magnetic fields generated by machines, electric motors or loudspeakers.
• Attention, LED light:
Do not look directly into the LED light!
Do not look directly or with optical instruments into the light!
• If it can be assumed that safe operation is no longer possible, the product must
be turned off and precautions must be taken to ensure that it is not used uninten-
tionally. Disconnect all poles of the product from the mains voltage (remove the
associated fuse or switch off the automatic circuit breaker). After this, arrange for
an expert to check the product.
• Safe operation can no longer be assumed if:
- the product shows visible signs of damage
- the product does not work at all or well (flickering light, leaking smoke or a smell
of burning, the light flickers, audible cracking noises, discolouration to the prod-
uct or the adjacent surfaces.)
- the device was stored for a longer period of time in unfavourable conditions
- it was exposed to heavy loads during transport
• Do not carelessly leave the packaging material lying around, since it could become
a dangerous plaything for children.
• On industrial sites, the accident prevention regulations of the association of the
industrial workers' society for electrical equipment and utilities must be followed!
• If you have doubts about how the equipment should be operated or how to safely
connect it, consult a trained technician.
• Maintenance, adjustment and repair work may be carried out only by an expert or
a specialist workshop.
• If you have any questions that are not answered in these operating instructions,
please contact our technical customer service or another specialist.
