4 White
13Ch mode
Ch. Function
1 Dimmer
Strobe
2
functions
3 Red
4 Green
5 Blue
6 White
Color Macro
7 (override
RGBW)
000 - 255 White 0%-100%
Values
000 - 255 Red 0%-100%
000 - 005 Strobe open
006 - 010 Strobe closed
011 - 033 Plus Random, slow->fast
034 - 056 Ramp up Random, slow -> fast
057 - 079 Ramp down Random, slow -> fast
080 - 102 Random Strobe Effect, slow -> fast
103 - 127 Strobe Break Effect, 5s.....1s (Short burst with
break)
128 - 250 Strobe slow -> fast <1Hz - 20Hz
251 - 255 Strobe open
000 - 255 Red 0%-100%
000 - 255 Green 0%-100%
000 - 255 Blue 0%-100%
000 - 255 White 0%-100%
000 - 005 Color OFF
006 - 013 Red
014 - 021 Amber
022 - 029 Yellow Amber
030 - 037 Yellow
038 - 045 Green
046 - 053 Turquoise
054 - 061 Cyan
062 - 069 Blue
070 - 077 Lavender
078 - 085 Mauve
22
Whtie
Sub-group
Dimmer
Green
Multifunctional
-strobe
Red
Green
Blue
White
Color Macro
