DMX Kanäle
2Ch mode
Ch. Function
1 Dimmer
Color Macro
2 (override
RGBW)
3Ch mode1
Ch. Function
1 Dimmer
2
Strobe
Values
000 - 255 0%-100%
000 - 005 Color OFF
006 - 013 Red
014 - 021 Amber
022 - 029 Yellow Amber
030 - 037 Yellow
038 - 045 Green
046 - 053 Turquoise
054 - 061 Cyan
062 - 069 Blue
070 - 077 Lavender
078 - 085 Mauve
086 - 093 Magenta
094 - 101 Pink
102 - 109 Warm White
110 - 117 White
118 125 Cold White
126 127 Color jumping stop
128 191 Color jumping Speed slow->fast/Colour1->12
192 255 Color fading Speed slow->fast/Colour1->12
Values
000 - 255 0%-100%
000 - 255 Strobe Open
006 - 010 Strobe Close
011 - 250 Strobe slow->fast<1Hz-20Hz
20
Sub-group
Dimmer
Color Macro
Sub-group
Dimmer
Strobe
