SPECIFICATIONS:
77314
SKU
MODEL
LD19S
Microbolometer:
Type Uncooled
Resolution, pixels 384x288
Refresh rate 9 Hz
Spectral range, µm 7.7-13.2
Optical characteristics:
Magnification, x
1.1 - 2.2
Digital zoom, x 2
Objective lens
19 mm, F/1.2
Close-up range, m
Exit pupil, mm
Field of view, degree / m@100m
- horizontal
26.8 / 50.5
- vertical 20.8 / 38
Diopter adjustment, D
Max. detection range, m/yd*
500 / 547
Display:
Type
Resolution, pixel 640x480
Operational characteristics:
Start-up time, sec
Power supply
Battery type
External power supply 8,4-15 V
Operating time on battery
pack EPS3 / EPS5), h
Operating time on a battery
set**, h, approx.
Degree of protection, IP
code (IEC60529)
Video output
PAL/NTSC
green
Body color
Operating temperature
Dimensions, mm 180x86x58
inch 7x3.4x2.3
Weight (without batteries), kg / oz 0.32 / 11.3
* Max. detection range of an object measuring 1.7x0.5 m
Operation in power saving mode.
**
For improvement purposes, design of this product is subject to change.
Quantum XD50S
2
77315 77312 77316 77322
XD19S LD38S XD38S LD50S
Uncooled Uncooled
384x288 384x288
9 Hz 50 Hz
50 Hz 9 Hz
7.7-13.2 7.7-13.2
1.1 - 4.4 2.1 - 4.2 2.1 - 8.4 2.8 - 5.6
2 / 4 2 2 / 4 2
38 mm, F/1.2 50 mm, F/1.2
3
3
8 8
14.4 / 25
11 / 19.2
10.8 / 19 8.3 / 14.4
+5/-5 +5/-5
950 / 1039 1250 / 1367
OLED OLED
640x480 640x480
9
9
4÷6 V
4÷6 V
4xАА
4xАА
8,4-15 V 8,4-15 V
9 / 20 9 / 20
5,5 5,5
IPХ4 IPХ4
PAL/NTSC PAL/NTSC
black green black green
-25 °С to +50 °С / -13 °F to +122 °F
200x86x59 207x86x59
7.9x3.4x2.3 8.1x3.4x2.3
0.35 / 12.3 0.43 / 15.2
Quantum XD38S Quantum XD19S
1

PACKAGE CONTENTS

Thermal Imaging Scope
Carrying case
User manual
77317
Video cable
XD50S
Hand strap
2
50 Hz
DESCRIPTION
Digital thermal imaging scopes Quantum based on IR sensor (uncooled
2.8 - 11.5
microbolometer) are represented by a number of models featuring
2 / 4
various frame rate, magnification and lens diameter. The scopes are
5
designed for the use both in the nighttime and in the daylight in inclement
5
weather conditions (fog, smog, rain) to see through obstacles hindering
detection of targets (branches, tallgrass, thick bushes etc.). Unlike the
image intensifier tube based night vision devices, thermal imaging
+5/-5
scopes Quantum do not require an external source of light and are not
affected by bright light exposure.
The Quantum XD series features stadiametric rangefinder, multiple
OLED
color modes and 50 Hz frame rate.
Thermal imaging scopes Quantum have a wide range application
9
including night hunting, observation and terrain orientation, search and
4÷6 V
rescue operations.
4xАА
9 / 20 3
FEATURES
5,5
Detector size 384x288 pixels
IPХ4
Quality OLED display (640x480 pixels)
Stadiametric rangefinder*
black
Multiple color modes*
Optical magnification 1.1x/2.1x/2.8x
2x (LD series) / 2x-4x (XD series) digital zoom
Display off function*
Three calibration modes - manual, semiautomatic and automatic
Three operation modes - city, forest, identification
Defective pixel repair option
Power saving mode
Wide field of view
External power supply
Video output enabling recording
Image inversion modes: "White hot" and "Black hot"
Two ¼" tripod mounts
* Available in XD series only.
Automotive cigarette lighter adapter
Spare battery container
Cleaning cloth
Warranty card
3
