Petporte smart flap
Important: Before assembling or disassembling the unit, always ensure that the power is turned off and any installed battery is
removed (see Figures on page 10-12).
1. Offer the porch up to the front of the exterior section of the Cat Flap (see Figure 1), ensuring that the wire and connector pass through the rectangular
opening on the porch and exterior section.
2. Insert the four plastic "mushroom" pins through the holes on the reverse side of the exterior section of the Petporte smart flap
Figure 2).
3. From the inside of the porch, secure the plastic "mushroom" pins in place with the "horseshoe" clips (see Figure 3).
4. Next, remove the Extension Tunnel from the interior section and remove the four self-tapping fixing screws from the large cover plate separating it from the
main unit (see Figure 4).
5. Remove the transparent door flap.
6. Feed the Porch Cable from the porch and through the rectangular opening on the interior section (see Figure 5). Mount the exterior section with attached
porch over the tunnel molding on the interior section.
7. Temporarily attach the external and interior sections using the two supplied M6 screws through the exterior section and loosely screw into the interior
section (see Figure 6a).
8. Connect the porch wire and connector onto the electronics board. Any excess cable should be routed to the right of the battery compartment (see
Figure 6b).
9. Attach the low voltage power cable to the power connector on the left of the electronics board and route the cable along the cable guides so that the
wire passes through one of the slots at the bottom of the Petporte smart flap
to run on battery-power ONLY, you can also attach a 9-volt (IEC 6LR61) battery and insert it into the battery compartment below the electronics board.
Please note that there is reduced functionality in battery-only mode (see the "Battery Backup Facility" section of the Installation Guide for more details).
10. Replace the transparent door flap ensuring that the ridge around the door is inward facing.
1 1. Place the large cover plate over the interior section and loosely screw in place using the four self tapping screws for testing purposes (see Figure 8).
12. If not already in position click the small cover plate in place over the battery compartment (see Figure 9).
13. Power up your Petporte smart flap
transparent door flap against the green lock to activate a switch. There will be a small mechanical click. Only use the power supply included with the
product. Using an unauthorised power supply will invalidate your guarantee and may damage the Cat Flap.
14. Now please refer to the programming instructions (below) to record your cat's microchip number into your Petporte smart flap
programmed you need to ensure that the Petporte smart flap
Repeat this for all of your cats that you want to be programmed in (see Figure 10a and 10b).

Programming Cats Into the Petporte smart flap

Because your Petporte smart flap
®
no animals programmed in the unit. The door locks will also open, allowing free access for any animal to enter or exit. When programming the Petporte smart
flap with an animal, ensure that your pet is nearby as you have 30 seconds in which to introduce the animal to the scanner (porch). You may wish to enlist the
®
help of another person, as cats are naturally suspicious of anything new!
Press and hold the Green Button for about 10 seconds until the green light stays illuminated and then release the Green Button. A beep should sound and the
red light should stop flashing with only the green light left flashing. You now have 30 seconds to pass the cat underneath the porch. There is no need to post
the cat through the Petporte smart flap
of the animal; it is that part of the animal that needs to be under the porch area in order to program the unique identification number for that animal. Once the
microchip has been successfully scanned, the Petporte smart flap
its locked position.
If this procedure fails the first time or if you exceed the programming time, simply repeat the process.You will need to program the unit with each of your cats by
using this method. Your Petporte smart flap
Only once you are completely satisfied that your Petporte smart flap
Petporte smart flap .
®
Assembly (For Testing Purposes Prior to Installation)
®
by plugging in and/or turning on the mains supply or temporarily activate the battery by gently pushing the
®
can reliably read the microchip at the distance that your cat will approach it when installed.
®
is initially supplied unprogrammed, when it is first powered both the green and red lights will flash to indicate that there are
as this can lead to unnecessary stress for the animal. Microchips are normally implanted between the shoulder blades
®
will beep three times. The green light will stop flashing, and the green lock will come up to
®
can be programmed with up to 25 cats.
®
Replacement flaps available online
(see Figure 7). Do not plug in or turn on the power. For the back-up facility or
®
®
works with all your cats' microchips, prepare to install your
®
and through the porch (see
®
. Once your cat is
®
