B -REMOTE INSTALLATION OF THE DECLIC WITH CONFORT PRO OR MISTRAL 800 MOTOR
See the specific instruction booklet supplied when fitting the remote controlled Confort or Mistral 800
motorat a distance from the Declic extractor hood.
1.Turn the screws anticlockwise to loosen the 2 fixing clips on the Declic (fig 1).
2.The Declic is supplied with a 10mm and 20mm spacer to fill the gap between the wall and the rear
ofthe extractor. To fit the spacer unscrew the screws located between the halogen lights and remove
thefront light housing in order to access (fig.5).
3.Cut the require aperture in the base of the kitchen cabinet as indicated (fig. 6).
4.Insert the telescopic extractor in the aperture in the kitchen cabinet and turning the screws clockwis-
esecure the assembly to the kitchen cabinet (fig 1).
5.Insert the grommets into the screw holes (fig 8).
6.Connect the ducting onto the round outlet on the top of the motor assembly.
7.Connect both appliances together (fig 9) and connect them to the mains supply
(See ELECTRICALWIRING chapter).
CAUTION : If the kitchen cabinet does not have a door you must execute points 6 and 7 before-
point 4.
C -REPLACING THE DECORATIVE FRONT STRIP
You can replace the strip in the front trim with a matching strip of kitchen furniture finish or with a com-
pletepiece of cornice.
1.Remove the glass (See chapter 6: MAINTENANCE).
2.When replacing the front strip with matching laminate. Firstly, remove the right-hand end capping
fromthe front trim and slide out the aluminium front strip plate. Secondly, insert the cut piece of
laminateand replace the right-hand end capping.
3.When replacing the whole front trim with a piece of lighting pelmet or similar. Firstly, remove the right-
hand end capping and the aluminium strip to access to the front fixing screws. Secondly, cut the
newfront trim in accordance with the dimension contained in fig.14 and machine finish the new strip
beforefixing the trim and metal plate using the original screws (fig.15).
4 OPERATION
Access to the functions by opening of the side.
•Lighting : By rock-switch ON / OFF ( Fig. 16 ).
• Motor : By dimmer switch ( Fig. 17).
Automatic stop of the functions by closing of the side.
5

USEFUL HINTS

• To obtain the best performance we recommend you to switch 'ON' the cooker hood a few minutes (in
the boost setting) before you start cooking and you should leave it running for approximately 15 minutes
after finishing.
• IMPORTANT: NEVER DO FLAMBÉ COOKING UNDER THIS COOKER HOOD
• Do not leave frying pans unattended during use as over-heated fat and oil might catch fire.
• Do not leave naked flames under this cooker hood.
• Switch 'OFF' the electric and gas before removing pots and pans.
• Ensure heating areas on your hotplate are covered with pots and pans when using the hotplate
