Electrical Safety Instruction

For grounded plugs only
IF THE MAINS LEAD OF THE APPLIANCE
IS FITTED WITH A GROUNDED PLUG:
FUSE REPLACEMENT
If the mains lead of this appliance is fitted
with a BS 1363A 13 amp fused plug, to
change a fuse in this type of plug use a
A.S.T.A. approved fuse to BS 1362 type and
proceed as follow:
1. Remove the fuse cover (A)
2. Remove the fuse (B)
3. Fit replacement fuse into plug
4. Refit the fuse cover
B
IMPORTANT:
The fuse cover mast be refitted when
changing a fuse and if the fuse cover is lost
the plug must not be used until a correct
replacement is fitted.
Correct replacements are identified by the
colour insert or the colour embossed in words
on the base of the plug. Replacement fuse
cover are available from your local electrical
store.
fi 100325
Users- & Installation Instruction Cooker Hoods
A
CONNECTION TO A REWIREABLE
PLUG
If the fitted plug is not suitable for your socket
outlet, then it should be cut off and disposed
of in order to avoid a possible shock hazard
should it be inserted into a 13A socket
elsewhere.
A suitable alternative plug should then be
fitted to the cable.
The wires in this mains lead are coloured in
accordance with the following code:
BLUE
BROWN
YELLOW & GREEN "EARTH"
YELLOW & GREEN
N
BLUE
Connected to a
typical 13 amp plug
1. The YELLOW & GREEN wire must be
connected to the terminal in the plug
which is marked with the letter E
or by the Earth symbol
or coloured green or yellow & green
2. The BLUE wire must be connected to the
terminal which is marked with the letter N
or coloured black
3. The BROW wire mast be connected to
the terminal which is marked with the
letter L
or coloured red
2
GB
"NEUTRAL" (N)
"LIVE" (L)
(E)
E
N
BROWN
CABLE CLAMP
