17. Parts List

Mod.
Part
No.
2
3
6
10
9
11
14
12
10
13
15
15
16
16
17
18
19
21
20
22
21
22
23
14
MSPK950IX
Part Name
1 Extensible pipe
2 inside Chimney
3 outside Chimney
4 inside chimney bracket
5 outside chimney bracket
6 Outlet
7 Hook
8 Power cord
9 Casing and shell assembly
Outskirt assembly
PCB box assembly
PCB assembly Capacitor
Front board
Halogen
Blower
Impeller
Motor
Grid
Push button switch
Aluminium Filter
GB
QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
2
5
3
