14. APPLIANCE OPERATING
Key and switch functions (depending on model)
C D
E
2 3
C D E
C D E
C D E
Operating panel
A Stop
B Power level 1
C Power level 2
D Power level 3
E Light ON/OFF
A Motor ON/OFF
B Power level 1
C Power level 2
D Power level 3
E Light ON/OFF
A Light ON/OFF
B Motor ON/OFF / Power level 1
C Power level 2
D Power level 3
E Operation indicating lamp
D Light ON/OFF
C Power level 3
B Power level 2
A Power level 1
Operation indicating lamps
A Power level 1
B Power level 2
C Power level 3
D Light ON/OFF
E Operation indicating lamps
Drawings are for Illustration purposes only
