Control Board

Enter the menu by pressing the MODE-button. Browse through the menu by pressing UP or DOWN. Press
ENTER in order to select the desired menu. You can change the selection by pressing UP or DOWN. Press
ENTER in order to confirm. You can leave every mode by pressing MODE. The functions provided are
described in the following sections.

Menu structure

LCD
ADDRESS CODE ADD
000
MASTER
FUNCTION
Perform 000
PERFORM
Perform 001
FUNCTION
Perform 002
CHANNEL
MODE
ManDim
000
VERSIONS
Interconnecting several devices (master/slave operation)
Several devices may be interconnected (max. 32). Then all slave units can be synchronized and controlled
with the master unit without the need for a DMX controller. The devices must be set to the corresponding
operating modes.
1 In order to set the Master device, press the MODE button so many times until MASTER FUNCTION is
indicated on the display and confirm with the ENTER button Now choose ON and press ENTER again
2 Connect the DMX output of the master unit to the DMX input of the first slave unit. Then connect the
DMX output of the first slave unit to the DMX input of the second slave unit, etc. until all units have been
connected in a chain. Make sure the master unit is the first in the chain. Do not connect a DMX controller
to the DMX input of the master unit.
3 Set the master unit to the desired operating mode. The interconnected devices will now operate
synchronously.
DMX address setting
001 ~ 511
Off
Master setting
On
Enabling of ManDim setting and of DMX operation
(Master setting on off)
LED full on (irrespective of ManDim setting)
Internal strobe program (when DMX 2CH is set)
LED full on (irrespective of ManDim setting)
1CH
Setting DMX channel mode
2CH
Man_Data
Dimmer with increasing brightness
000-255
Version
Software version of each IC
(Ver.1.0)
Function
