DESCRIPTION OF THE DEVICE
1. Mounting bracket
2. Fixation screw
3. Shutter blades
Device rear:
7
DMX
8
IN
1: Ground
2: Signal (–)
3: Signal (+)
4: NC
5: NC
DMX
OUT
9
ON
OFF
10
1
2
3
1: Ground
2: Signal (-)
3: Signal (+)
MODE ENTER
DOWN
UP
FUSE: T 3.15 A, 250 V
POWER IN
POWER OUT
11
12
13
4
5
6
4. Focus knob
5. Zoom knob
6. Color filter frame fixation clips
7. Handle
8. DMX In (5-pin)
9. DMX Out (5-pin)
14
10. On/Off switch
11. Power input
DMX
15
12. LCD with operating buttons
IN
13. Power output
DMX
16
14. DMX signal indicator
OUT
15. DMX In (3-pin)
16. DMX Out (3-pin)
17
17. Fuseholder
17/24
00113335.DOCX, Version 1.0
