Connecting When using multi-core data communication cables with a diameter up to
Multi-core a max. of 6 mm, both cables are fed through the rubber insert and th-
Data Commu- rough the opening intended for this purpose like with the RJ 45 cable.
nication Ca-
bles to the The following work steps are for data communication cables with a maxi-
Fronius String mum diameter of 6 mm.
Control 250/25
1
DCD DF
2
3
*
Strip approx. 50 - 70 mm of insulation from the end of the data com-
munication cable
*
2
1
*
10mm
1
Silicon tube 510 mm
25
