Telephone connection : Voltages present on the
telecommunication network are classified TNV-3
(Telecommunication Network Voltage) according to the
EN60950 standard.
Setting up the Door Bell
1. The door bell can be carried around by the people
who need assistance
2. The door bell can be fixed on the wall or door
surround. Drill two holes horizontally, 14mm apart.
Insert the two supplied anchors into the two holes.
Hang the door bell onto the two anchors and then
insert and tighten the screws. Finally, stick the
blank sticker over the two holes.
3. The door bell can be stuck onto a door or window
using the supplied strong adhesive tape. Remove the
protective paper from the adhesive tape on the back
of the door bell and then stick to the required door,
window or surface.

Wall Mounting

1. Drill two holes horizontally, 96mm apart, and leave the
screws protruding from the wall by 5mm.
2. Hang the base on to the two screws and pull the base
down to lock it on.
INSTALLATION
3
