Operating Instructions
Four-indent crimping tool DigiCrimp® with digital display and wear monitoring
1
Type CR 2025 battery compartment
2
Clamping screw for locking the crimper setting
3
Contact bushing with locking screw
4
Crimping point
5
Display
6
MODE button (recessed)
7
ON/OFF button
8
Crimp setting adjustment wheel
9
Opening to the emergency open lever
10
Stop
Pictograms mark the text as follows: Read and observe these notes, and exercise special
care in these cases. Pass on all work safety precautions to users and specialist staff.
WARNING
This information indicates a potentially dangerous situation that may lead to
serious injury or fatality.
ATTENTION
This information indicates a potentially dangerous situation that may lead to slight
or minor injury, or damage to property.
Info
This information refers directly to the description of a function or operating
sequence.

2 Operation

Switching on and off
Switch the crimper on or off by pressing the ON/OFF switch (7).
Select the display
Your crimper has a variety of display functions for selection by pressing the recessed MODE
switch (6). This allows you to show the crimping stamp setting in mm, inches or the selector
positions as given in M22520/1-01.
Briefly press the MODE button (6) with the gauge provided to change the setting. This will
show the various display modes in the following order:
Rev.: 2013-12-02
EN
4 / 10
