I
1. MOVIMENTAZIONE
Il prodotto va sollevato e movimentato con cura.
2. IMPIEGHI
Movimentazione di acque pulite non aggressive prive di gas disciolti,
con moderata presenza di gas solo per i modelli BG e BGM garden.
Impieghi tipici
Rifornimenti idrici domestici, irrigazioni, pressurizzazione, travasi.
3. LIMITI D'IMPIEGO
• Max pressione d'esercizio: 800 kPa (8 bar). PSA: 1MPa (10bar)
• Max temperatura liquido: P, BG, SP, HM: 40°C; CEA-CA-PSA:
85°C, 110°C in versione ... - V.
• Max temperatura ambiente: 40°C (per 40÷45°C vedere punto 5)
• Max nr. Avviamenti orari: 40

4. INSTALLAZIONE

Fissare l'elettropompa ad una base stabile con opportune viti, utiliz-
zando le asole predisposte sul piede motore.
Installazione corretta (fig. 1)
A = riduzioni eccentriche
B = pendenza positiva
C = buona immersione
D = curve ampie
E = diametro tubo d'aspirazione >= diametro bocca della
pompa
F = dislivello di sollevamento. Dipende dalla pompa e
dall'installazione (*)
G = tubazioni non gravanti sulla pompa ma supporti
indipendenti
H = valvola di fondo (non indispensabile per modelli SP-BG-SG)
(*) Il dislivello di aspirazione è determinato dalla temperatura del
liquido, della quota altimetrica, delle perdite di carico e del
NPSH richiesto dalla pompa.
Indicativamente il dislivello in aspirazione è 4m per i modelli P e
C e 7m per i modelli BG e SP.
Installazione errata (fig. 2)
1 = curva brusca; alte perdite di carico
2 = immersione insufficiente: risucchio d'aria
3 = pendenza negativa: sacche d'aria
4 = diametro tubo < al diametro bocca della pompa: alte
perdite di carico.
5. COLLEGAMENTO ELETTRICO
Eseguire i collegamenti come indicato sul retro del coperchio mor-
settiera (rotazione antioraria) o in fig. 4 per le versioni monofase e in
fig. 5 per le versioni trifase. Usare cavi a normativa con 3 condutto-
ri (2+terra) per versioni monofase e con 4 conduttori (3+terra) per
versioni trifase. Le caratteristiche di riferimento (tensione, frequenza
e corrente assorbita) sono riportate sulla targhetta della pompa.
Le elettropompe monofase hanno la protezione termoampero-
metrica a riarmo automatico incorporata; le elettropompe trifase
vanno alimentate sempre tramite un salvamotore magneto-ter-
mico tarato alla corrente di targa.
Per temperatura ambiente da 40 a 45°C si dovranno utilizzare
cavi di alimentazione con caratteristiche di temperatura non
inferiore a 95°C e con sezione minima dei conduttori di 1,5 mm
Controllo del senso di rotazione (solo trifase)
L'esatto senso di rotazione è orario guardando la pompa dal lato
motore.
La verifica si effettua a vista, guardando la ventola o
controllando la prestazione della pompa.
Il senso di rotazione corretto è quello che genera prestazioni
Q/H maggiori. In caso di rotazione contraria invertire tra di loro
due fili di alimentazione.
6. ADESCAMENTO (Fig. 3)
Riempire attraverso l'apposito tappo il corpo pompa e il tubo
aspirante facendo fuoriuscire tutta l'aria.
Per i modelli SP-BG l'autoadescamento senza valvola di fondo
può richiedere anche 3-4 minuti. Per questo si consiglia sempre
l'impiego della valvola di fondo.

7. MANUTENZIONE

Qualsiasi intervento sulla pompa deve essere eseguito da per-
sonale qualificato previo scollegamento dalla rete. La pompa
non richiede manutenzione ordinaria.
GB
1. HANDLING
The product must be lifted and handled with care.
2. APPLICATIONS
Designed to handle clean non-aggressive water free of
dissolved gases. For water with moderate gas content, use BG
and BGM garden models.
Typical applications.
Domestic water supply, irrigation, pressure boosting, liquid
transfer.
3. WORKING LIMITS
• Max. operating pressure: 800 kPa (8 bar), PSA; 1 MPa (10 bar)
• Max. liquid temperature: P, BG, SP, HM: 40°C; CEA-CA-PSA:
85°C, 110°C for ...- V version.
• Max. ambient temperature: 40°C (for 4045°C see point 5).
• Max. number of starts per hour: 40
4. INSTALLATION
Screw the electric pump to a stable base using the slots in the
foot of the motor.
Proper installation (fig. 1)
A = eccentric adapters
B = positive lift
C= good immersion
D= wide bends
E = suction pipe diameter >= pump port diameter
F = suction lift. Depends on pump and installation (*)
G= pipes must not exert stress on pump but on independent supports
H= foot valve (not necessary for SP-BG-SG models).
(*) The suction lift is determined by liquid temperature, altitude,
flow resistance and
NPSH required by the pump.
As a general rule, the suction lift is 4 m for the P and C models,
and 7 m for the BG and SP models.
Improper installation (fig. 2)
1 = tight bends: high flow resistance
2 = insufficient immersion: air suction
3 = negative lift: air pockets
4 = pipe diameter < pump port diameter: high flow resistance.
5. ELECTRICAL CONNECTION
To connect, proceed as shown on the back of the terminal board
cover (anticlockwise rotation) and in fig. 4 for single-phase
versions, fig. 5 for three-phase versions. Use standard 3-wire
cables (2+ground) for single-phase versions, 4-wire cables
(3+ground) for three-phase versions.
The reference characteristics (voltage, frequency and input
current) are shown on the pump rating plate.
The single-phase pumps have built-in, automatic reset thermo-
amperometric protection; the three-phase pumps must always
be supplied through a magneto-thermal overload cutout set to
the rated current.
For ambient temperatures of 40 to 45°C, supply cables with
2
.
temperature characteristics of at least 95°C and minimum wire
gauge of 1.5 mm
2
must be used.
Check the direction of rotation (three-phase models only)
Clockwise rotation when looking at pump from the motor side.
Check by looking at the fan or by observing the pump's
performance.
The correct direction of rotation is the one that generates the
highest Q/H performance. In the event of incorrect rotation,
switch two supply wires.
6. PRIMING (Fig. 3)
Fill the pump body and suction pipe through the fill plug,
bleeding off all the air. For the SP-BG models, self-priming
without the foot valve may require up to 3-4 minutes.
We therefore recommend that you always use a foot valve.

7. MAINTENANCE

The pump should be serviced by qualified personnel only, after
having been disconnected from the power mains. No routine
maintenance is required.
