EN
SLOPE MODE
Slopes can be set manually up to 5° (± 9 %).
Press button
Press button
The MAN LED is illuminated.
Choose the relevant axis (X, Y, Z) by pressing button
SLOPE
Horizontal operation:
One axis (X or Y) can be set manually, the other axis is automatically self-levelled.
Vertical operation:
The direction of the X axis can be set manually, the Y axis is self-levelled.
In both horizontal and vertical operation the TILT and / or V-W-S function can be activated.
MAN
Horizontal operation:
In this mode both (X and / or Y) axes can be set manually.
Vertical operation:
Both (X and Z) axes can be set manually. In horizontal and vertical operation TILT and V-W-S cannot be
activated.
Press button
After leaving the slope function the TILT function is not active. If required press button
38
to enter the SLOPE function. The SLOPE LED is illuminated.
once more to switch to the MAN function.
to quit the SOPE / MAN mode.
of the remote control.
.
