TILT ALARM FUNCTION
After POWER ON the laser automatically activates the TILT function. The TILT LED is flashing during the
activation procedure. When it is completed (after 90 sec. approx.) the LED is illuminated.
If the laser is disturbed the rotation stops and the laser beam and TILT LED will flash.The laser will not
re-level automatically.
If required the self-levelling procedure can be re-activated by pressing button
To quit the TILT function press button
If the laser is disturbed due to a positional change of the tripod it will automatically self-level itself
(within the self-levelling range of 5°), a height offset can occur. This will be avoided by using the TILT
function. The use of this function ensures that the laser is shut off even within the self-levelling range if
the laser is disturbed. Switch the unit on and wait until the self-levelling procedure is completed.
VIBRATION-WIND-SECURITY FUNCTION (V-W-S)
Press button
When the V-W-S LED and the TILT LED are both illuminated the V-W-S function is activated.
The V-W-S function automatically activates the TILT function. This function allows continuous operation
during periods of vibration and wind. If a significant movement occurs the laser stops rotating and the
TILT LED and the laser beam start flashing. Press the V-W-S button
Press the V-W-S button

SCANNING MODE

Press button
Press button
180° -> 90° -> 45°-> 10° -> 45° -> 90° -> 180°.
Press button
Press button
36
to activate the V-W-S. The V-W-S LED is illuminted and the TILT LED starts flashing.
once more for re-activation.
to select the scanning function. The scan angle is 180°.
to change the scan angle:
to orientate the scan line in a clockwise direction and button
to quit the scanning function.
.
.
to cancel.
for anticlockwise.
