Application examples

The potential applications for the monitor are varied, the following examples are
EN
just typical applications which demonstrate the electrical connection and the as-
sociated configuration of the monitor and clarify individual functions. If you requi-
re more detailed information or assistance for your application, please consult
your Motec customer service department or the Motec Service Hotline.
11.1 HGV with rear and side camera
(indicator-activated)
After engaging reverse gear, the monitor should automatically switch on and
display the rear-view camera (high priority).
The direction of travel indicator (right-hand indicator) is used to automatically
display the side view camera.
