Instructions for installation and use

10. Technical data

The measurements of the various power rating variants can be found in Fig. 5
and Fig. 6 on page 26.
Power
Article
rating
number
QUBE-090
QUBE-105
QUBE-120
QUBE-150
Article Stone weight
number
QUBE-090
QUBE-105
QUBE-120
QUBE-150
WORLD OF WELLNESS
Cabin
volumes
3
[kW] [m ]
9,0 9 - 14
10,5 10 - 15
12,0 14 - 18
15,0 18 - 25
[kg]
ca. 35
ca. 35
ca. 60 3 x 16 / 3 x 10
ca. 60 3 x 16 / 3 x 10
Minimum size of
ventilation opening
[mm]
350 x 50
350 x 60
350 x 70
350 x 90
Fuse [A]
3 x 16 400 V AC 3N~ 50/60 Hz
3 x 16 400 V AC 3N~ 50/60 Hz
400 V AC 3N~ 50/60 Hz
400 V AC 3N~ 50/60 Hz
p. 25/26
Weight
without
stones
[kg]
34
34
40
40
Supply voltage
