14
Glue the ruderhorn with epoxy. The rudder-
horn should stick nearly to the flat area in
the flap.
16
Fix the flap to the maximum up position
(Speed position). Mount the clevis to the
rudder horn.
15
Sand the bottom of the wing and the servo
mount thoroughly. Pull the cable of the ai-
leron servo and a female servo connector
through this part of the wing.
17
Adjust the servo to the maximum throw with
the servo horn facing to the leading edge of
the wing. Fix the servo in the mount using
the plastic strip and self tapping screws.
