Tomahawk CYCLONE Handbuch Seite 20

ENGLISH
Locate all parts for this step.
Use sandpaper to sand the bottom of the
wing and the servo mount.
20
ASSEMBLY THE AILERON
01
03
02
Center the servo with a servo tester. Add th-
readlock to the servo screw and install the
servohorn perpendicular. Remove any arm
that may interfere with the operation of the
servo. Install the servo in the servo mount.
Thread the nut and the clevis on the threa-
det rod. The threadet rod should protrude as
shown in the foto.
04
Route the servo cable in the wing and glue
the the servo mount with the installed ser-
vo in the wing. We recommend Uhu Endfest
300. Please note that this glue takes several
hours to cure.
