8. SYSTEM SETTINGS

This mode allows you to change important system
settings for the controller.

Calling the System Settings

01.Patch fixture
Fig. 8.1 Calling the system settings
1
Keep the button MENU for 2 seconds to call
the system settings.
• The display indicates the first menu item
"01.Patch fixture".
2
Turn the pan wheel to browse the menu
items.
3
Press the button ENTER to select the
desired menu item.
4
Turn the pan wheel to change a setting and
confirm with ENTER.
5
Shortly press the button ESC to abort the
setting procedure and return to the main
menu level.
6
To save your settings and exit the system
settings, keep the button MENU pressed for 2
seconds.
The following adjustments are possible:
Indication Function
01. Patch fixture
DMX configuration
02. Reset factory Reset to factory settings
03. Delete all Delete all DMX address
Fixture patch assignments
04. Fade mode Fade function
05. RDM DMX RDM DMX address
Address setup assignments
06. Data backup Data backup
07. Data load Data import
08. Send fixture
Firmware update
Update file
09. Black-out mode Blackout function
#1
This menu item is covered in chapter 6.
#2
This function is not available.
Reset factory [Reset to factory
settings]
Here you can reset the controller to factory
setting.
1
Call the menu item with the pan wheel and
confirm with ENTER.
2
Select the setting [YES] with the pan wheel
and confirm with ENTER.
• The display shortly indicates "Reset factory
Please wait G." and then "OK" as soon as
the factory settings are loaded.
Delete all Fixture patch [Delete all
DMX address assignments]
All address assignments and control channel
options made can be deleted and reset to the
presettings.
1
Call the menu item with the pan wheel and
confirm with ENTER.
2
Select the setting [YES] with the pan wheel
if a reset is to be made. Confirm with
ENTER.
• The display shortly indicates "SAVE OK" and
returns to the main menu level.

Fade mode [Fade function]

The fade function can be assigned to all control
#1
channels or only to the pan and tilt wheels.
1
Call the menu item with the pan wheel and
confirm with ENTER.
2
Use the pan wheel to select the setting [ALL
CHANNELS] if the fade function is possible
for all control channels or select [ONLY
PAN/TILT] if it is only possible for the pan
and tilt wheels. Confirm with ENTER.
• The display shortly indicates "SAVE OK" and
#2
returns to the main menu level.
