Playing a Chase

A chase must be programmed before you can
call it. Chases can be played manually, time-
controlled or sound-controlled. As a basic setting,
the manual mode is activated. The LEDs
MANUAL, MUSIC and AUTO indicate the current
setting.
1
There should be no device or illumination
scene selected. If one of the control LEDs of
the number buttons 1-16 light, press the
corresponding button for deselecting.
2
Press the button CHASE.
• The control LED lights.
Manual
Chase01 Step001
Fig. 7.11 Calling a chase
3
Use the number buttons 1-16 to select the
desired chase.
• The control LED flashes.
• If necessary, use the button PAGE to switch
between the two channel groups 1-16 (LED
A lights) and 17-32 (LED B lights).
• Up to 5 chases can be selected
simultaneously. The chases are played one
after the other. The LED of the chase
currently playing flashes, the others light.
• The display indicates the number of the
chase (e.g. "Chase01") in the lower line and
the current step (e.g. "Step001).
4
Select the chase running mode with the
button RUN MODE. The mode is indicated
by the LEDs next to the button.
Manual
Chase05 Step080
Fig. 7.12 Chase in manual mode
• MANUAL: The chase can be manually
advanced step by step with the pan wheel.
Music
Sensitivity 050%
Fig. 7.13 Chase in sound-controlled mode
• MUSIC: The individual steps of the chase
run to the rhythm of the music picked up via
the internal microphone.
The sensitivity of the sound control is
adjustable. For this, keep the button RUN
MODE pressed and turn the tilt wheel to
adjust a value between 0-100 %. The higher
the value, the higher the sensitivity.
Auto
Wait 1M10S
Fig. 7.14 Chase in automatic mode
• AUTO: The individual steps of the chase run
at the adjusted speed and fade time.
Use the pan wheel to adjust the running
speed, i.e. how long a scene is shown,
between 10 minutes and 0.1 seconds
(indication "Wait").
Use the tilt wheel to adjust the fade time, i.e.
the time between the steps, between 0 and
30 (indication "Fade").
5
A flashing LED indicates which chase can be
adjusted when several chases are selected
simultaneously. The chase selected last can
be adjusted. To adjust a different chase
instead, keep the corresponding number
button pressed until its LED flashes.
6
To stop a chase, press the corresponding
number button so that its LED extinguishes.
Adjusting Fade In for the Color
Channels
Manual
Fade 8.5S
Fig. 7.15 Adjusting a fade in time
It is possible to adjust a fade in time for chases
affecting the RGBW color channels 1-4 and the
dimmer channel. The controller automatically
creates all necessary intermediate values.
Keep the button FIXTURE pressed and
simultaneously adjust the fade in time with the
pan wheel between 0-30 seconds. When turning
the wheel, the display indicates the selected value
in the lower line, e.g. "Fade 8.5S" for a fade in
lasting 8.5 seconds.
