Inverting Output Values; Assigning The Fade In Function - EuroLite DMX MOVE CONTROL 512 Bedienungsanleitung

the control elements. The display indicates
the control element in the upper line, e.g.
"Fader CHANL:1/R " and the DMX channel in
the lower line, e.g. "DMX channel:01"
Fader CHANL:1/R
DMX channel:01
Fig. 6.2 Channel assignment
5
Adjust the first control element with the pan
wheel, e.g. 1/R = sliding control 1 and
assign the DMX channel with the tilt wheel.
DMX
Control
channel
1/red 1
2/green 2
3/blue 3
4/white 4
5/dimmer 5
6 6
7 7
8 8
9 9
Tab. 6.2 Assignment of DMX channels to the control elements
6
Press the button ENTER to memorize your
setting.
• To confirm the memory procedure, all LEDs
of the controller flash three times.
7
Repeat the steps 5 and 6 to assign further
DMX channels.
8
Press the button DEL to delete an
assignment (indication „NULL").
• To confirm the deleting procedure, all LEDs
of the controller flash three times.
9
After your settings, exit the system settings.
For this, keep the button MENU pressed for
2 seconds.

Inverting Output Values

It is possible to individually invert the output
values of the 512 control channels. The
adjustment can be made in the system settings.
1
Keep the button MENU pressed for 2
seconds to call the system settings.
2
The display indicates the first menu item
„01.Patch fixture" (otherwise select it with the
pan wheel). Press the button ENTER to
begin with the configuration. The display
indicates "PLEASE SELECT FIXTURE".
3
Use the number buttons 1-16 to select the
unit of which the DMX channels are to be
inverted (control LED lights).
DMX
Control
channel
10 10
11 11
12 12
13 13
14 14
15 15
16 16
PAN 17
TILT 18
4
Select the option FADER REVERSE with the
button SWAP. The display indicates the
control element in the upper line, e.g.
"FADER:1/R " and the current setting in the
lower line, e.g. "REVERSE:NO".
Fig. 6.3 Inverting output values
5
Adjust the first control element with the pan
wheel and use the tilt wheel to select the
setting [YES] if the output value of the control
channel is to be inverted or [NO] if not. With
activated inversion the output value is zero if
the control channel has been set to the
maximum value and vice versa.
6
Press the button ENTER to memorize your
setting.
• To confirm the memory procedure, all LEDs
of the controller flash three times.
7
Repeat the steps 5 and 6 to invert further
control channels.
8
Repeat the steps 3, 5 and 6 to adjust further
units.
9
After your settings, exit the system settings.
For this, keep the button MENU pressed for
2 seconds.

Assigning the Fade In Function

The fade in function for the RGBW color channels
1-4 and the dimmer channel can be individually
assigned to each device. The adjustment can be
made in the system settings.
1
Keep the button MENU pressed for 2
seconds to call the system settings.
2
The display indicates the first menu item
„01.Patch fixture" (otherwise select it with the
pan wheel). Press the button ENTER to
begin with the configuration. The display
indicates "PLEASE SELECT FIXTURE".
3
Use the buttons number buttons 1-16 to
select the unit to be configured (control LED
lights).
4
Select the option COLOR FADE with the
button SWAP.
FIXTURE:01 [NO]
Fig. 6.4 Assigning the fade in function
29/40
FADER:1/R
REVERSE:YES
COLOR FADE
