MOVEMENT COLOR:1
SPEED:42%
Fig. 7.3 Adjusting parameters
• Color effects 10-16: The running speed can
be adjusted between 1 and 100 % (indication
"MOVEMENT SPEED").

Memorizing Illumination Scenes

32 memory banks are available for illumination
scenes. Each scene contains the values of all
control channels including the pan and tilt settings
of the connected light effect units as well as
movement patterns or color effects at the time of
storage.
Program
Fig. 7.4 Programming mode
1
Call the programming mode. For this, keep
the REC pressed until the LED above the
button lights.
2
Press the button FIXTURE.
• The control LED lights.
3
Use the number buttons 1-16 to select the
devices to be controlled.
• The corresponding LEDs of the buttons light.
• If a number button is pressed once again,
the corresponding device is deselected.
Program
CH:02 Val:098
Fig. 7.5 Adjusting DMX values
4
Adjust the desired DMX values (0-255) for
the DMX channels using the sliding
controls and, if necessary, the pan and tilt
wheels.
• As soon as a fader is moved, the display
indicates the number of the control channel
in the lower line and the current output value
as a DMX value.
5
If necessary, movement patterns or color
effects can be integrated in the scene. For
this, call the effect mode with the button
MOVEMENTS and select the desired effect
with the number buttons 1-16. Exit the
effect mode again by pressing the button
FIXTURE.
6
If necessary, use the button PAGE to switch
between the two channel groups 1-16 (LED
A lights) and 17-32 (LED B lights) and repeat
steps 3 and 5, until the desired values are
assigned to all channels.
7
Deselect the adjusted devices with the
corresponding number button 1-16.
8
Repeat the steps 3 to 5 for all further devices
to be adjusted.
9
Press the button SCENE and then the button
REC to memorize the scene.
10
Select the desired memory bank with one of
the number buttons 1-16.
• If necessary, use the button PAGE to switch
between the two channel groups 1-16 (LED
A lights) and 17-32 (LED B lights).
• To confirm the memory procedure, all LEDs
of the controller flash three times.
11
Repeat the steps 2 to 10 to memorize further
scenes.
12
After all desired scenes have been
memorized, switch off the programming
mode. For this, keep the button REC
pressed until the LED above the button
lights.

Calling Illumination Scenes

Static scenes from the memory bank can only be
used in manual mode.
1
There should be no device selected. If one of
the control LEDs of the number buttons 1-
16 light, press the corresponding button for
deselecting.
2
Press the button SCENE.
• The control LED lights.
3
Call the desired scene with the number
buttons 1-16.
• The control LED lights.
• If the button is pressed once again, the
scene is deselected (control LED
extinguishes).
• If necessary, use the button PAGE to switch
between the two channel groups 1-16 (LED
A lights) and 17-32 (LED B lights).
