7. OPERATION

Switch on the controller with the rear power
switch. The unit is in manual mode and the
display indicates "Manual" in the upper line.
Manual Adjustment of an Illumination
Scene
An illumination scene contains the values of all
control channels including the pan and tilt settings
of the connected light effect units.
1
Press the button FIXTURE.
• The control LED lights.
2
Use the number buttons 1-16 to select the
units to be controlled.
• The corresponding LEDs of the buttons light.
• If a number button is pressed once again,
the corresponding device is deselected.
• Instead of selecting each device individually,
devices with consecutive numbers can be
selected simultaneously. For this, press the
first and last number button simultaneously.
Example: For selecting the devices 1 to 8,
press the number buttons 1 and 8
simultaneously. Thus, all 8 devices will be
selected simultaneously. In the same way, it
is possible to deselect devices again.
Manual
CH:02 Val:098
Fig. 7.1 Adjusting DMX values
3
Adjust the desired DMX values (0-255) for
the DMX channels using the sliding
controls and, if necessary, the pan and tilt
wheels.
• As soon as a fader is moved, the display
indicates the number of the control channel
in the lower line and the current output value
as a DMX value.
4
The 32 light effect units are combined in 2
groups (channel pages) of 16 channels each.
If necessary, use the button PAGE to switch
between the two channel groups 1-16 (LED
A lights) and 17-32 (LED B lights) and repeat
steps 2 and 3, until the desired values are
assigned to all channels.
Adjusting an Illumination Scene with
Movement Patterns and Color effects
The built-in effect generator allows creating 9
different movement patterns for pan and tilt
movement of moving heads or scanners as well
as 7 additional color effects for LED light effect
units. The effects can be saved together with
other DMX values in a scene.
1
Press the button FIXTURE (control LED
lights) and use the number buttons 1-16 to
select the devices to be assigned to an
effect.
• If necessary, used the button PAGE to
switch between the two channel groups 1-6
(LED A lights) and 17-32 (LED B lights).
2
Call the effect mode with the button
MOVEMENT.
• The control LED lights.
3
Select the desired movement patterns or
color effect with the number buttons 1-16.
• The selected devices will begin to perform
the movement pattern or color effect.
• Number buttons 1-9: Create movement
patterns designed for pan and tilt movement
of moving heads or scanners.
• Number buttons 10-16: Create color effects
for all kinds of LED light effect units.
• For optimum results of the color effects
triggered by buttons 15 and 16, the operation
with a least 8 devices is recommended.
4
The parameters of the movement patterns
and color effects can be edited and adapted
to your particular application.
MOVEMENT RANGE
PAN:050% TL:080%
Fig. 7.2 Adjusting parameters
• Movement patterns 1-9: Press the button
SWAP to switch between the parameters
and adjust the values with the Pan/Tilt
wheels.
- MOVEMENT RANGE: The pan/tilt movement
can be adjusted between 1 and 100 %.
- MOVEMENT OFFSET: Correction values can
be adjusted for fine adjustment of the pan/tilt
movement.
- MOVEMENT SPEED: The running speed can
be adjusted between 1 and 100 %.
- DELAY LEVEL: The delay time for the
operation with several devices can be
adjusted between 0 and 30 seconds.
