22 | English
Delete all images
In the "Delete all images" menu, you can delete all the files in
the internal memory at once.
Press the "Func" 6 button to call up the measuring functions.
Now press the right-hand function button 7 and select
"Tool" > "Delete all images". Press the right-hand arrow
button 8 to enter the submenu. Then press either the left-
hand function button 13 under the tick symbol to delete all
files, or the right-hand function button 7 under the cross sym-
bol to cancel the operation.

Data Transmission

Data Transmission via USB Interface
Open the cover on the micro USB port 3. Connect the micro
USB port on the measuring tool to your PC or laptop using the
micro USB cable provided.
Now press button 9 to switch on the thermal imaging camera.
Open the file browser and select the "BOSCH GTC 400 C"
drive. The saved JPG files can be copied, moved to your com-
puter or deleted from the internal memory of the measuring
tool.
As soon as you have ended the required operation, discon-
nect the drive following the standard procedure and then use
button 9 to switch the thermal imaging camera off again.
Remove the micro USB cable during the measurement opera-
tion and close the cover 3.
Attention: Always disconnect the drive from your operating
system first (eject drive), as failure to do so may damage the
thermal imaging camera's internal memory.
Always keep the cover of the USB interface closed so that
dust and splashes cannot enter the housing.
Note: Only connect the measuring tool to a PC or notebook.
The tool could be damaged if you connect it to a different de-
vice.
Note: The micro USB interface can only be used for data
transmission – it is not suitable for charging batteries.
Troubleshooting – Causes and Corrective Measures
In the event of a fault, the tool will restart and can then continue to be used. If the fault persists, the following overview may
help you.
Error
Measuring tool cannot be switched on.
1 609 92A 3RD | (24.7.17)
Post-editing the thermal images
You can post-edit the saved thermal images on your computer
if it uses a Windows operating system. To do so, download the
GTC Transfer software from the product page for the thermal
imaging camera at www.bosch-professional.com/gtc.
Data transmission via WLAN
The measuring tool is equipped with a WLAN module which
enables the saved images to be wirelessly transmitted from
your thermal imaging camera to a mobile device.
The "Measuring Master" application (app) is required as the
software interface for this. You can download this from the
store for your end device type:
In addition to wirelessly transmitting your images, the
"Measuring Master" application makes it possible for you to
use an extended range of functions and facilitates post-edit-
ing and forwarding of measured data (for example via e-mail).
Information about system requirements for a WLAN connec-
tion can be found on the Bosch website at
"www.bosch-professional.com/gtc".
To activate or deactivate the WLAN connection on the meas-
uring tool, call up the main menu, use the buttons to select
"WLAN" and activate or deactivate it. e will appear on the dis-
play. Ensure that the Wi-Fi interface is activated on your mo-
bile device.
The connection between the mobile device and the measur-
ing tool can be established after the Bosch application has
been started (if Wi-Fi modules are activated). To do this, fol-
low the instructions in the "Measuring Master" application.
Cause Corrective Measure
Battery pack or batteries Charge the battery pack or change the batteries.
empty
Battery too warm or too cold Allow the battery to reach the correct temperature or
change it.
Measuring tool too warm or Allow the measuring tool to reach the correct temper-
too cold ature.
Image memory defective Format the internal memory by deleting all images
(see "Delete all images", page 22). If the problem
persists, send the measuring tool to an authorised
Bosch after-sales service agent.
Image memory full If required, transfer the images to another storage
medium (e.g. computer or notebook). Then delete
the images in the internal memory.
