Important!
The vibration value changes according to the area of
application of the electric tool and may exceed the
specified value in exceptional circumstances.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever
necessary.
Switch the appliance off when it is not in use.
Wear protective gloves.

5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
5.1 Dust extraction
5.1.1 Installing the dust extractor adapter
(Figure 3/Item 15)
Slide the dust extractor adapter (15) on to the
connection for the dust extractor (6).
You can then connect a suitable dust extractor (a) to
the dust extractor adapter (15) (dust extractor not
supplied).
This will provide excellent dust extraction on the
workpiece.
Check that all the parts are properly connected.
Important. The vacuum cleaner you use for the
extraction work must be suitable for the workpiece
material.
5.1.2 Installing the dust collection box
(Figure 4/Item 14)
Push the dust collection box (14) to the dust extractor
connection (6). Remove the dust collection box in
reverse order.
The dust is extracted directly via the grinding/sanding
belt into the dust container.
17.12.2009 10:24 Uhr Seite 11
Important.
For health safety reasons it is imperative that you use
a dust container or a dust extraction system via the
dust extraction adaptor!
5.2 Adjusting the additional handle
(Fig. 5/Item 2)
Slacken the screw (1) and move the additional handle
(2) to its optimal position. Lock the additional handle
(2) in place by tightening the screw (1).
5.3 Changing the sanding / grinding belt
(Fig. 6-7/Item 13)
Pull the clamping lever (12) to the outside to
relieve the tension in the sanding/grinding belt.
Pull the used sanding/grinding belt off the drive
rollers.
Slide the new sanding/grinding belt on to the
drive rollers.
Ensure that the direction of the sanding/grinding
belt (arrows on the inside of the sanding/grinding
belt) is identical to the direction of the belt
sander/grinder (arrow over the rear drive roller).
Press the clamping lever (12) to the rear to
tension the sanding/grinding belt.
5.4 Adjusting the position of the belt
(Fig. 8/Item 8)
Hold the belt sander/grinder with the
sanding/grinding plate at the top.
Switch on the belt sander/grinder.
By turning the setting screw (8) the belt position
should be set so that the sanding/grinding belt is
at the center of the two drive rollers.
5.5 Moving sanding/grinding belt cover
(Fig. 9 – 10/Item 9)
Important.
The moving sanding/grinding belt cover may
only be swung upwards if the pushbutton (7) has
been pressed.
Press the pushbutton (7) and at the same time
swing the cover (9) upwards.
Release the pushbutton.
The cover will lock in its end position.
To swing the cover back down again, press the
pushbutton (7) again. The cover can then be
swung downwards.
