cing conditions.
Warning! Due to the high risk of bodily injury to
the user, the equipment may not be used to grind
up branch or hedge clippings. Moreover, the
equipment may not be used as a power cultivator
to level out high areas such as mole hills.
For safety reasons, the scarifi er may not be used
as a drive unit for other equipment or toolkits of
any kind, unless specifi cally advised to do so by
the manufacturer.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

Mains voltage: ................................ 230 V ~ 50Hz
Power input: ............................................ 1200 W
Working width: ............................................31 cm
Number of blades: ...................... 8 double blades
Scarifying depth: ......................... -3 / 3 / 7 / 9 mm
LpA sound pressure level: ..................... 85 dB(A)
LWA sound power level: ........................ 99 dB(A)
Vibration at the handlebars: ................. 2.71 m/s²
K uncertainty: ......................................... 1.5 m/s²
Protection class: .......................................... II / ®
Protection type: .............................................IPX4
Weight: .......................................................8.4 kg
Danger!
Sound and vibration
Sound and vibration values were measured
in accordance with EN ISO 3744: 1995, EN
ISO 11201: 1995, EN 1033:1995.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
Anl_GC_ES_1231_SPK1.indb 16 Anl_GC_ES_1231_SPK1.indb 16
GB
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment's construction and layout:
1. Damage to hearing if no suitable ear protec-
tion is used.
2. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.

5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
The scarifi er is delivered unassembled. The com-
plete push bar must be assembled and mounted
before using the scarifi er. Follow the operating
instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the
equipment.
Fitting the push bar brackets (see Figs. 3-4)
Insert the push bar brackets (Fig. 3/Item 7) into
the provided openings (Fig. 3). Then fasten the
brackets with the retaining screws (Fig. 4/Item
12).
Fitting the lower push bar (see Fig. 5)
•
Slide the lower push bar (Fig. 5/Item 6) over
the push bar brackets.
•
Screw the tubes together, using the screws
supplied (Fig. 6/Item 11).
Fitting the upper push bar (see Figs. 6-8)
•
Position the upper push bar (Fig. 1/Item 5)
such that its holes line up with the holes of the
lower bar.
•
Screw the tubes together, using the screws
supplied (Fig. 2/Item 11).
