AUTOPULS II - Factory setting
Setting possibilities Area
Primary parameters:
1 Welding current Area depends on
program
Wire feed speed
Thickness of material
2 Arc length -9.9 - +9.9
Secondary parameters:
1 (DC) Inductance -5.0 - +5.0
1 (Pulse) Pulse frequency +/-50
2 Gas pre flow 0.0 - 10.0
3 Soft start Off / 1.5 - 18.0
4 Hotstart time 0.0 - 10.0
5 Slope down 0.0 - 10.0
6 Burnback 1 - 30
7 Gas post flow 0.0 - 10.0
8 DUO Plus TM (MIG) 0 - 50
9 Stop amp 0 - 100
r Remote control 0 = internal
1 = torch control
Tack welding (manual setting)
Setting possibilities Area
2 Gas pre flow 0.0 - 10.0
4 Hotstart time 0.0 - 10.0
5 Slope down 0.0 - 10.0
7 Gas post flow 0.0 - 10.0
* reducable for faster tack welding (may result in lack of gas shielding)
Step Factory setting Unit
2T/4T
1 Depending on A
program
0.1 m/min
0.1 mm
0.1 0.0 V
0.1 0.0 -
1 0 %
0.1 0.2 s
0.1 1.5 m/min
0.1 0.5 s
0.1 0.2 s
1 5 ms
0.1 3.0 s
1 25 %
1 50 %
0
Step Recommended setting Unit
0.1 0.2* s
0.1 0.0 s
0.1 0.0 s
0.1 3.0* s
501 3774 K
QUICKGUIDE AUTOPULS II
Programs
No: Wire Material
P106 Ø 0.6 mm Fe SG2 ER70S6
P101 Ø 0.8 mm Fe SG2 ER70S6
P109 Ø 0.9 mm Fe SG2 ER70S6
P102 Ø 1.0 mm Fe SG2 ER70S6
P116 Ø 0.6 mm Fe SG2 ER70S6
P111 Ø 0.8 mm Fe SG2 ER70S6
P119 Ø 0.9 mm Fe SG2 ER70S6
P112 Ø 1.0 mm Fe SG2 ER70S6
P201 Ø 0.8 mm CrNi ER 316 LSI
P209 Ø 0.9 mm CrNi ER 316 LSI
P202 Ø 1.0 mm CrNi ER 316 LSI
P311 Ø 0.8 mm AlMg ER5356/ER5554
P319 Ø 0.9 mm AlMg ER5356
P312 Ø 1.0 mm AlMg ER5356/ER5554
P313 Ø 1.2 mm AlMg ER5356/ER5554
P359 Ø 0.9 mm AlSi5 ER4043
P352 Ø 1.0 mm AlSi5 ER4043
P353 Ø 1.2 mm AlSi5 ER4043
P369 Ø 0.9 mm AlMg3Mn ER5554
P372 Ø 1.0 mm AlSi12 ER4047
P373 Ø 1.2 mm AlSi12 ER4047
P501 Ø 0.8 mm CuAl8 Brazing
P509 Ø 0.9 mm CuAl8 Brazing
P502 Ø 1.0 mm CuAl8 Brazing
P561 Ø 0.8 mm CuSi3 Brazing
P569 Ø 0.9 mm CuSi3 Brazing
P562 Ø 1.0 mm CuSi3 Brazing
UK
Gas Process
CO (100) DC+
2
CO (100) DC+
2
CO (100) DC+
2
CO (100) DC+
2
ArCO (82/18) DC+
2
ArCO (82/18) DC/P+
2
ArCO (82/18) DC/P+
2
ArCO (82/18) DC/P+
2
ArCO (98/2) DC/P+
2
ArCO (98/2) DC+
2
ArCO (98/2) DC/P+
2
Ar (100) DC+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
Ar (100) DC/P+
