MCD 201 Series
5
6 MCD 201 – XXX –
A
kW @ 400 VAC, 40 ºC
A
Model kW
007 7.5
015 15
018 18
022 22
030 30
037 37
045 45
055 55
075 75
090 90
110 110
007 7.5
015 15
018 18
022 22
030 30
037 37
045 45
055 55
075 75
090 90
110 110
B L1, L2, L3
T4 3Ø, 200-440 VAC, 45-66 Hz
T6 3Ø, 200-575 VAC, 45-66 Hz
C A1, A2, A3
CV1 24 VAC & 24 VDC
CV3 110-240 VAC & 380-440 VAC
MG.17.A4.7K – VLT is a registered Danfoss trademark
2
mm (AWG)
MCD 201-007 ~ MCD 201-037 ~
MCD 201-030 MCD 201-055
10 - 35 25 - 50
(8 - 2) (4 - 1/0)
10 - 35 25 - 50
14
(8 - 2) (0.55) (4 - 1/0)
mm (inch)
Torx (T20) Torx (T20)
3 Nm 4 Nm
2.2 ft-lb 2.9 ft-lb
7 mm 7 mm
3 Nm 4 Nm
2.2 ft-lb 2.9 ft-lb
YY – ZZZ
B C
A AC53b
18 A
34 A
42 A AC53b 4-6:354
48 A
60 A
75 A
85 A
100 A AC53b 4-6:594
140 A
170 A
200 A
17 A
30 A
36 A AC53b 4-20:340
40 A
49 A
65 A
73 A
96 A
120 A AC53b 4-20:580
142 A
165 A
MCD 201-075 ~
MCD 201-110
11
N.A.
(0.43)
8.5
26
(1.02) (0.33)
14
N.A.
(0.55)
mm (inch) mm (inch)
N.A.
N.A.
2
mm (AWG)
MCD 201-007 ~
MCD 201-110
0.14 - 1.5
(26 - 16)
0.14 - 1.5
6
(0.24)
(26 - 16)
mm (inch)
N.A.
3.5 mm
0.5 Nm max
4.4 lb-in max
