Epson ELPCB02 Installationsaleitung

Werbung

Connection & Control Box Installation Manual / Connection & Control Box Installationsanleitung /
Included Items
Penholder
Connection & Control Box
(1.5 m)
(1.8 m)
AC adapter
Power cable
AC adapter holder
Cable cover
HDMI Cable Clamp
Template sheet
Installation manual (This manual)
Document CD-ROM
Functions
What Y
ou Prepare /
RS-232C (CROSSOVER, NULL MODEM / クロスケーブル)
×4
2.5
×2
2.5
Screws / Schrauben / Vis / Viti / Tornillos / Parafusos / 取り付け用ネジ
Cables / Kabel / Câbles / Cavi / Cables / Cabos / ケーブル類
Please prepare cables for each device to connect with this product.
Video and audio output ports connected to
the projector.
Indicates the status of this product.
Sets the audio output method.
Turns the power on or off.
Video and audio input ports connected to
each device.
Connects to the supplied AC adapter.
