Mixer Controls
6. Input Selector: Set this switch to the desired audio source from this channel: PC (a track
playing on that layer in the software) or Line (a device connected to the Line/Phono
Inputs on NS6II's rear panel).
Note: The Line/Phono switches on NS6II's rear panel must also be set properly. Also, a
channel's controls will only send MIDI information when its Input Selector is set to PC.
7. Gain Trim: Adjusts the pre-fader, pre-EQ audio level of the corresponding channel in the
software.
8. LED Meters: Monitors the audio levels of the corresponding channel.
9. Channel Treble: Adjusts the high (treble) frequencies. When Touch Mode is activated,
touching this knob will mute the corresponding channel's high frequencies (an "EQ kill").
10. Channel Mid: Adjusts the mid-range frequencies. When Touch Mode is activated,
touching this knob will mute the corresponding channel's mid-range frequencies (an "EQ
kill").
11. Channel Bass: Adjusts the low (bass) frequencies. When Touch Mode is activated,
touching this knob will mute the corresponding channel's low frequencies (an "EQ kill").
12. Channel Fader: Adjusts the audio level on the corresponding channel in the software.
13. PFL: Press this button to send this channel's pre-fader signal to the Cue Channel for
monitoring. When engaged, the button will be lit. By pressing one PFL button at a time,
you will cue that channel alone (and deactivate PFL monitoring for the other channels). To
cue to multiple channels simultaneously, press the PFL buttons for those channels at the
same time.
14. Crossfader Assign: Routes the audio playing on the corresponding channel to either side
of the crossfader (A or B), or bypasses the crossfader and sends the audio directly to the
Program Mix (center, Off).
15. Crossfader: Blends audio between the channels assigned to the left and right side of the
crossfader.
Note: The crossfader is user-replaceable if it should ever wear out. Simply remove the
facepanel, then remove the screws holding it in position.
16. Master Volume: Adjusts the output volume of the Program Mix.
17. Booth Volume: Adjusts the output volume of the Booth Output mix.
