wer supply capacity are listed in Table 2:
• During the installation of the sauna hea-
ting unit, make certain that the vertical
clearance between the upper edge of the
sauna heating unit and the sauna ceiling
is suffi cient . The horizontal (lateral) clea-
rance between the sauna heating unit and
the cabin wall is provided in the dimension
diagram of the respective sauna heating
unit. The required distance between the
lower edge of the sauna heating unit and
the fl oor is also provided by the dimen-
sion diagram. In case of fl oor-standing
ovens, the distance is determined by the
base. Fundamentally, it is important to
make sure that the sauna heating unit is
not placed on a fl oor that consists of an
easily fl ammable material (wood, synthe-
tic fl ooring or similar material). Ceramic
tiles or similar materials are practical in the
area of the sauna.
• The distance between the oven safety
grid or recliner bench and other fl ammable
materials and the sauna heating unit are
provided in the dimensional data of the re-
spective sauna heating unit. The safety
grid height must be approximately equal
to the frontal height of the sauna heating
unit.
16

Electrical connection

Your electrician will be able to accomplish
this work without further explanation in ac-
cordance with the provided wiring schematic
and with the help of the circuit diagram
mounted inside the respective control unit.
Be sure to note, however, that live wires
should not be visibly laid onto the inner cabin
walls due to safety considerations. For this
reason, the wall element with the air intake
vent is already equipped with cable conduits
in most sauna cabins
Should there be no cable conduits in your
cabin, drill an hole in the cabin wall imme-
diately adjacent to the sauna heating unit
where the cable projects from the sauna he-
ating unit and pull the cable through this hole
towards the exterior and then to the control
unit. The cable as well as all other connec-
ting lines (supply wire to the power source
and to the cabin lighting) on the outside wall
of the cabin should also be protected from
damage, for ex. by installation in cable con-
duits or by covering with wooden skirting
strips.
