MOUNTING THE GUARD
EN
WARNING:
Always wear gloves when mounting or
replacing the guard. Take care of the blade on the guard
and protect your hand from cutting.
WARNING:
Never operate the tool without the
guard firmly in place. The guard must always be on the
tool to protect the user! When the guard is fixed, never
attempt to remove or adjust the guard, if a replacement
is needed, it should be performed by a qualified service
technician!
1. Lift the trimmer head and face it downward; align the
two mounting holes in the guard with the two bolts that
are preassembled on the base of the shaft (Fig. B) .
2. Use the supplied hex wrench to lock the guard in place
with the two bolts (Fig. C).
Make sure the guard is fixed according to Fig. B & C, any
reverse fixing will cause great danger!
MOUNTING AND ADJUSTING THE FRONT-ASSIST
HANDLE
Push the front-assist handle onto the shaft (Fig. E), then
insert the clamping block into the handle slot (Fig. F), mount
the lock pole, and lock them with the wing nut (Fig. G). The
sequence is as Fig. D shown. Lastly, adjust the front-assist
handle between the soft sleeve and the label to make sure
your front arm is straight when using the trimmer (Fig. H)
and then lock the lever of the lock pole (Fig. I).
Fig. D & H parts description see below:
D-1 Front-assist Handle
D-2 Lock Pole
D-3 Clamping Block
NOTICE:
The front-assist handle should be turned
upwards to point toward the top of the rear handle.
WARNING:
Only fix the front-assist handle between
the soft sleeve and the label on the shaft.
WARNING:
The tool can not be used without the
front-assist handle securely fixed.
MOUNTING THE SHOULDER STRAP
1. Loosen and remove the bolt in the hook of the strap
(Fig. J & K).
2 Attach the hook onto the shaft as Fig. L shown and
lock it with the bolt (Fig. M).
WARNING:
Only fix the hook of the strap between the
housing and the soft sleeve on the shaft.
10
56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1500E-F
D-4 Wing Nut
H-1 Soft Sleeve
H-2 Warning Label

OPERATION

WARNING:
Do not allow familiarity with this
product to make you careless. Remember that a careless
fraction of a second is sufficient to inflict serious injury.
WARNING: Always wear safety goggles or safety
glasses with side shield,
along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
WARNING:
Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
WARNING: To prevent serious personal injury,
remove the battery pack from the tool before servicing,
cleaning, changing attachments or removing material
from the unit.
You may use this product for the purposes listed below:
Trimming: used for removing grass and weeds up against
walls, fences, trees and borders.
Cutting: used for cutting the grass that is difficult to
reach using a normal mower.
NOTICE:
The tool is to be used only for its prescribed
purpose. Any other use, for example edge trimming, is
deemed to be a case of misuse.
ATTACHING/DETACHING THE BATTERY PACK
Fully charge before first use.
To Attach
Align the battery ribs with the mounting slots and press the
battery pack down until you hear a "click" (Fig. N).
To Detach
Depress the battery-release button and pull the battery
pack out as Fig. O shown.
HOLDING THE LINE TRIMMER
WARNING:
Dress properly to reduce the risk of
injury when operating this tool. Do not wear loose
clothing or jewelry. Wear eye and ear/hearing protection.
Wear heavy duty, long trousers, boots and gloves. Do not
wear short trousers, sandals or go barefoot.
Before operating, stand in the operating position and
check for eye protection, proper clothing, balanced foot-
ing, straight arm, which holds the front-assist handle.
