Pistol Grip Duoplug Power
411-18311
Rev. B
3. Kofferinhalt
Kodierrippen-Schneidzange
Pistol Grip Handzange
Bild 2
Ersatzklingen
4. Verwendungszweck
Mit der Handzange lassen sich 2-9polige AMP
DUOPLUG
Power
Einzelleitungen
nach
114-18458-0 der Fa. Tyco Electronics kontaktieren.
Der Kabelabgang der Steckverbinder ist nach einer
Richtung vorgegeben.
Die Kontaktierung erfolgt nach dem Prinzip der
Schneid-Klemm-Technik.
Hinweis:
Das
Werkzeug
ist
beschriebenen Zweck zu verwenden.
5. Inbetriebnahme
1. Drehen Sie den Handgriff solange, bis der
Rastbolzen einrastet und den Handgriff fixiert (siehe
Bild 3).
Federleistengehäuse
Verarbeitungsspezifikation
ausschließlich
für
Seite / Page 5 of 14
3. Contents of case
Coding rib cutting pliers
Pistol grip hand pliers
4. Purpose of use
With the hand pliers AMP DUOPLUG Power female
mit
connectors 3-20position
single conductors according to the processing
specification 114-18458-0 of tyco Electronics.
The cable outlet of the socket plugs is specified for
one direction.
Contacting is effected according to the principle of
the cutting–clamping–method.
Important:
den
The tool shall be used exclusively for the purpose
as described above.
5. Startup
1. Turn the hand grip for such time until the index
bolt locks into position and fix-positions the hand
grip (refer to picture 3)
Pistol Grip Duoplug Power
411-18311
picture 2
Spare blades
can be contacted with
ECOC: EGC0 ; LOC: AI
Rev. B
