2.3. Optional motorization
- There are 3 versions available:
o
Motorized version ( see page 14 for more details):
•
•
•
•
•
•
•
•
'dead man key' version:
o
•
'Motorizable' version:
o
•
- All motorizations mounted on a separate bottom plate. Motor is always at the inside.

3.Guidelines for installation and gate lifting

7. Lift-up points for the unloading and positioning during the installation
The gate may only be lifted with the right equipment for manipulation and sufficient dimensioned for
the weight. By preference use a type flexible lift ropes with sufficient lifting capacity.
Lifting point
®
Robusta Freitragende Schiebetore/Cantilever sliding gate
Ed. February 2015
dental rack adjustable in height
Motor unit with integrated controller with an extra base plate for
mounting on foundation at the inside
Two RF transmitters with rolling code
photocells
active safety edges at the guiding post
1 safety edge in front of the wing
completely pre-cabled
Warning light
Motorizable execution with motor and key switch but no
safety devices
Manual execution with dental rack but lockpost not in line and without
lock
Lifting point
®
- Robusta
21/36
