GETTING STARTED

Please follow the procedure shown below. The batteries are not installed and the power is "OFF".
1

Installing the cash register

Find a stable surface near an AC outlet where the cash register will not subject to water sources or
direct sunlight .
2

Initializing the cash register

In order for the cash register to operate properly, you must initialize it before operating for the first time.
Follow this procedure.
1.
Insert the manager (MA) key into the mode switch and turn it to the REG
position.
2.
Insert the plug of the AC power cord into the AC outlet. The buzzer will sound
three times.
IMPORTANT: This operation must be performed without batteries installed.
3.
The cash register has now been initialized. The register display will show "0.00"
with " ".
If the buzzer does not sound when the plug is inserted, the initialization has not been done
successfully. (This will occur when the voltage is high because you operated the cash register
before starting initialization.) Wait at least one minute after pulling out the plug and insert the plug
again.
3

Installing batteries

Three new R6 or LR6 batteries ("AA"size) must be installed in the cash register to prevent the data and
user-programmed settings from being erased from the memory, when the power cord is accidentally
disconnected or in case of power failure. Once installed, the batteries will last approximately one year before
needing replacement. At this time, the "
and must be replaced within two days. If the no battery symbol "
once.
Install three new R6 or LR6 batteries ("AA"size) according to the procedure shown below with the power cord
connected and set to the REG position:
1.
Lift the rear of the printer cover and detach it.
Be careful with the paper cutter, so as not to cut yourself.
2.
Open the battery compartment cover.
Page 7
" symbol will appear on the display to indicate the batteries are low
OPX/Z
PGM
" appears, you must install the batteries at
REG
MGR
X1/Z1
X2/Z2
7
