• Insulation damage due to being ripped out of the wall
socket,
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not be
used and are life-threatening due to the insulation dam-
age.
Check the electrical connection cables for damage regu-
larly. Ensure that the connection cables are disconnected
from electrical power when checking for damage.
Electrical connection cables must comply with the appli-
cable VDE and DIN provisions. Only use connection ca-
bles of the same designation.
The printing of the type designation on the connection ca-
ble is mandatory.
Safety information for replacing damaged or defective
mains connection cables
Connection type X
If the mains connection cable of this product is damaged,
it must be replaced by a specially prepared mains con-
nection cable which can be obtained from the manufactur-
er or its service department.
10.2 AC motor
Connections and repair work on the electrical equipment
may only be carried out by electricians.
• Before commissioning, ensure that the mains voltage
matches with the operating voltage on the type plate.
• Extension cables up to 25 m long must have a cross-
section of 1.5 mm².

11 Cleaning and maintenance

WARNING
Have maintenance and repair tasks that are
not described in this operating manual, car-
ried out by a specialist workshop. Use only
original spare parts.
WARNING
Improper maintenance or cleaning work can
cause injuries!
WARNING
The product may start unexpectedly and cause inju-
ries and burns during cleaning, repair and mainte-
nance work.
– Switch the product off.
– Pull out the mains plug.
– Allow the product to cool.
11.1 Cleaning
WARNING
Do not spray the product with water or clean it under
running water. There is a danger of electric shock and
the product could be damaged.
• Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth or blow it off with
compressed air at low pressure. We recommend that
you clean the product directly after every use.
• Never immerse the product in water or other liquids
for cleaning.
• Clean the product at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product. Make sure that no water can pen-
etrate the product interior.
• Always keep the product clean, dry and free from oil
or grease. Remove dust after each use and before
storage.
11.2 Maintenance
There are no parts which can be repaired by the user
within this product. Contact a qualified professional to
have the product checked and repaired.
• Check the product for obvious defects such as loose,
worn or damaged parts before each use.
Required tool:
• Two-pin spanner (2a)
• Lubricating grease tube (10)
11.2.1
ATTENTION
Product damage!
If the product is operated without lubricating grease or
with too little lubricating grease or with used lubricating
grease, this can lead to product damage.
– Do not use used grease!
– Check the lubricating grease level before each start-
up.
The product has a grease-lubricated lubrication system.
Change the lubricating grease every 40-50 operating
hours.
1. Place the product on a level, even surface.
2. Remove the cover (2).
Use a two-pin spanner (2a).
3. Check whether the transmission needs lubricating
and, if necessary, apply some lubricating grease to
the opening.
4. Re-fit the cover (2).
Use a two-pin spanner (2a).
5. After a short running time, check the lubricating
grease level by opening the lubricating grease cover
(2) again.
The lubricating grease level should be sufficient and
evenly distributed.
6. If the lubricating grease level is too low, repeat the
process.
11.2.2
ATTENTION
The carbon brushes must only be replaced by an elec-
trician.
www.scheppach.com
Filling in lubricating grease (Fig. 7)
Carbon brushes (2) (Fig. 2)
