6.2

Installation

For comfortable installation you can pull the
cable through the cable inlets after having
removed the breakout openings.
To install the Multi IO Box, please proceed as follows:
• Open the cover (B). Therefore, unscrew both
lower screws with an appropriate screwdriver and
remove the cover afterwards (see fig. 3).
• Connect the protective conductor to connecting
terminal PE (C).
• Connect the phase conductor to connecting
terminal L (D) .
• Connect the neutral conductor to connecting
terminal N (E) .
• Connect e.g. the boiler to connecting terminal 4
(F) or a circulation pump to connecting terminal
5 (G).
• You can expand the installation depending on
the installation conditions or according to your
personal needs (e.g. for ventilation control). For
further information regarding the connection
options please refer to section „6.3 Connections"
on page 50.
• Close the cover again. Therefore, push the
latches of the cover into the openings provided
and fasten the screws.
Start-up
49
