General system information

This device is part of the Homematic IP smart home
system and works with the HmIP radio protocol. In
connection with the Homematic IP Access Point,
the Homematic IP Multi IO Box can be configured
comfortably and individually with a smartphone using
the Homematic IP app. The available functions provided
by the Homematic IP system in combination with other
components are described in the Homematic IP User
Guide. All current technical documents and updates are
provided at www.eQ-3.de.
5

Mounting

You can flexibly mount the Multi IO Box on walls using
the supplied screws and plugs.
Alternatively, you can mount the Multi IO Box
with the Homematic IP DIN-Rail Adapter HmIP-
DRA (available as an option). For further
information, please refer to the user manual of
the DIN-rail adapter.
For mounting the Multi IO Box using screws, please
proceed as follows:
• Please select a suitable mounting location close
to your heating system.
