A
M
B
 Open the window.
 Mark the centre (M) of the textile window seal
 Mark the centre of the window frame.
 Adhere the hook and loop fastener to the window frame of the bottom-hung window (in-
side, on the side where the window handle is located), about 1 cm from the edge.
 First, attach the hook and loop fastener completely on side (A) and then on side (B), start-
ing in the centre. When mounting, point (A) must be exactly opposite point (B).
 When closing the window, care must be taken to ensure that the textile seal between the
sash and the window frame is not jammed.
 Preferably open the zip at the places marked "S" and attach the exhaust air hose there.
A
M
B
Fig. 12 – Mounting on bottom-hung window
Fig. 13 – Mounting on roof window
A
M
B
B
M
A
DE
FR
NL
ES
IT
EN
