Scope Of Delivery/Accessories; Overview; Description Of Functions - Parkside Performance Ppbks 56 C3 Originalbetriebsanleitung

The device is part of the X 20 V TEAM
series and can be operated with batteries
of the X 20 V TEAM series. Batteries of the
X 20 V TEAM series may only be charged
using chargers of the X 20 V TEAM series.

Scope of delivery/accessories

Unpack the device and check that
everything is present.
Dispose of the packaging material properly.
• Petrol Chainsaw
• Blade bar (pre-assembled)
• Saw chain (pre-assembled)
• Cutting aid
• Chain guard
• Oil bottle (500 ml, Organic saw chain oil)
• Fuel mixing bottle
• Combination tool
• Carrier bag
• Original instructions
• Rechargeable battery and charger with
instruction manual

Overview

The illustrations for the device
can be found on the front and
back fold-out page.
Fig. A
1 Front handle
2 Starter handle
3 Electric starter
4 Throttle lock
5 Rear handle
6 Hand protection
7 Throttle lever
8 Tank cover (Fuel)
9 Tank cover (Chain oil)
10 Saw chain
11 Blade bar
12 Chain catch
13 Chain brake lever/Front hand protection
14 Battery holder
15 Sprocket cover
16 Chain tensioner screw
17 Nut
18 Cold start lever (choke)
19 Fuel pump
20 Off button
21 Fuel mixing bottle
22 Oil bottle
23 Cutting aid
24 Chain guard
25 Combination tool
26 Carrier bag
27 Battery
28 Button (Charge level indicator)
29 Charge level indicator
30 Battery release
31 Charger
Fig. B
32 Oil regulating screw
Fig. C
33 Blade bar bolt
34 Sprocket
35 Receptacle (Chain tensioner pin)
36 Oil passage
37 Chain catching bolt
38 Chain tensioner pin
Fig. D
39 Cutting rod
40 End plate
41 Quick connector
42 Adapter nut
Fig. N
43 Wing nut
44 Air filter cover
45 Air filter
Fig. O
46 Spark plug connector
47 Spark plug
Fig. Q
48 Sight line/Felling direction indicator

Description of functions

The circulating saw chain is guided over
a blade bar (guide rail). The chainsaw is
equipped with a quick-stop chain brake.
An automatic oil system ensures continu-
ous chain lubrication. The device is provided
